6 Parameter Table
YASKAWA Europe TOMP_C710606_75A V1000 IP66 - Quick Start Guide EN 23
U1-24 Pulse Input frequency
Fault Trace
U2-01 Current Fault
U2-02 Previous Fault
U2-03 Frequency Reference at Previous Fault
U2-04 Output Frequency at Previous Fault
U2-05 Output Current at Previous Fault
U2-06 Motor Speed at Previous Fault
U2-07 Output Voltage at Previous Fault
U2-08 DC Bus Voltage at Previous Fault
U2-09 Output Power at Previous Fault
U2-10 Torque Reference at Previous Fault
U2-11 Input Terminal Status at Previous Fault
U2-12 Output Terminal Status at Previous Fault
U2-13 Drive Operation Status at Previous Fault
U2-14 Cumulative Operation Time at Previous Fault
U2-15 Soft-Starter Speed Reference at Previous Fault
U2-16 Motor q-Axis Current at Previous Fault
U2-17 Motor d-Axis Current at Previous Fault
Fault History
U3-01
to
U3-04
Lists the most recent fault that occurred through the fourth most
recent fault.
U3-05
to
U3-08
Accumulated operation time at the most recent fault through the
fourth most recent fault.
U3-09 to
U3-14
Lists the fifth most recent fault that occurred through the tenth most
recent fault.
U3-15 to
U3-20
Accumulated operation time at fifth most recent fault through the
tenth most recent fault.
* The following faults are not recorded in the error log:
CPF00, 01, 02, 03, UV1, and UV2.
DI/DO
Sel.
Description
Digital Input Function Selections
3 Multi-step speed reference 1
4 Multi-step speed reference 2
5 Multi-step speed reference 3
6
Jog frequency command (higher priority than multi-step speed
reference)
7 Accel/decel time selection 1
F Not used (Set when a terminal is not used)
14 Fault reset (Reset when turned ON)
20 to 2F
External fault; Input mode: N.O. contact / N.C. contact, Detection
mode: Normal/during operation
Digital Output Function Selections
0 During Run (ON: run command is ON or voltage is being output)
1 Zero Speed
2 Speed Agree
6 Drive Ready
E Fault
F Not used
10 Minor fault (Alarm) (ON: Alarm displayed)
Monitor Description
TOMP_C710606_75A_0_0_prePrint.pdf 55 21.12.2010 13:52:25

YASKAWA V1000 Series Specifications

General

Model	V1000 Series
Series	V1000
Output Frequency	0.1 to 400 Hz
Overload Capacity	150% for 60 seconds
Type	AC Drive
Control Method	V/f Control
Input Voltage	200-240V, 380-480V
Output Voltage	0 to Input Voltage
Power Range	0.1 to 18.5 kW
Horsepower	0.2 to 25 HP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Interfaces	Modbus RTU
Enclosure	IP20
Ambient Temperature	-10 to +50°C
Storage Temperature	-20 to +60°C
Humidity	5 to 95% RH (non-condensing)
Cooling Method	Fan Cooled
