YASKAWA V1000 Replacing Guide

VAN-V19001E [V1000→GA500]
33/35
Table 24: Carrier frequency and derating at normal duty (ND) rating - three-phase 400 V class
Normal
Duty
(ND)
Rating
(kW)
Model
Carrier Frequency and Derating (A)
C6-02=1
(2.0kHz)
C6-02=2
(5.0kHz)
C6-02=3
(8.0kHz)
C6-02=4
(10.0kHz)
C6-02=5
(12.5kHz)
C6-02=6
(15.0kHz)
CIPR-
GA50A

CIMR-
VA4A

0.1
4001
1.2
1.2
1.2
1.1
0.9
0.7
0001
1.2
1.2
1.2
1.1
0.9
0.7
0.2
4002
2.1
2.1
1.8
1.6
1.3
1.1
0002
2.1
2.0
1.8
1.6
1.4
1.1
0.6
4004
4.1
4.0
3.4
3.0
2.5
2.0
0004
4.1
3.8
3.4
3.0
2.5
2.0
0.8
4005
5.4
5.4
4.8
4.2
3.6
2.9
0005
5.4
5.1
4.8
4.3
3.6
2.9
1.1
4007
7.1
6.5
5.5
4.9
4.1
3.3
0007
6.9
6.2
5.5
4.9
4.1
3.3
1.5
4009
8.9
8.6
7.3
6.5
5.4
4.4
0009
8.8
8.0
7.2
6.4
5.3
4.3
2.2
4012
11.9
10.8
9.2
8.2
6.8
5.5
0011
11.1
10.2
9.2
8.1
6.8
5.5
3.0
4018
17.5
17.0
14.5
12.8
10.8
8.7
0018
17.5
16.2
14.8
13.1
11.0
8.9
3.7
4023
23.4
21.3
18.2
16.1
13.4
10.8
0023
23.0
20.5
18.0
15.9
13.4
10.8
5.5
4031
31.0
28.2
24.1
21.3
17.9
14.4
0031
31.0
27.5
24.0
21.3
17.8
14.4
7.5
4038
38.0
36.3
31.0
27.5
23.0
18.6
0038
38.0
34.5
31.0
27.5
23.0
18.6
11.0
4044
44.0
44.0
39.0
34.5
29.0
23.4
15.0
4060
60.0
54.5
46.3
40.8
33.9
27.0

YASKAWA V1000 Specifications

General

Input Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Frequency	0-400 Hz
Control Method	V/f control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Options	Modbus RTU
Ambient Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20°C to +65°C (-4°F to 149°F)
Humidity	95% (non-condensing)
Cooling Method	Forced Air Cooling
Enclosure	IP20
