YASKAWA V1000 Replacing Guide

VAN-V19001E [V1000→GA500]
34/35
Table 25: Carrier frequency and derating at heavy duty (HD) rating - single-phase 200 V class
Heavy
duty
(HD)
rating
(kW)
Model
Carrier Frequency and Derating (A)
C6-02=1
(2.0kHz)
C6-02=2
(5.0kHz)
C6-02=3
(8.0kHz)
C6-02=4
(10.0kHz)
C6-02=5
(12.5kHz)
C6-02=6
(15.0kHz)
CIPR-
GA50A

CIMR-
VABA

0.1
B001
0.8
0.8
0.8
0.8
0.7
0.6
0001
0.8
0.8
0.8
0.8
0.7
0.6
0.2
B002
1.6
1.6
1.6
1.6
1.4
1.3
0002
1.6
1.6
1.6
1.6
1.4
1.3
0.6
B004
3.0
3.0
3.0
3.0
2.7
2.4
0003
3.0
3.0
3.0
3.0
2.7
2.4
0.8
B006
5.0
5.0
5.0
5.0
4.5
4.0
0005
5.0
5.0
5.0
5.0
4.5
4.0
1.1
B010
8.0
8.0
8.0
7.5
7.0
6.4
0010
8.0
8.0
8.0
7.5
6.9
6.4
1.5
B012
11.0
11.0
11.0
10.4
9.6
8.8
0012
11.0
11.0
11.0
10.3
9.5
8.8
2.2
B018
17.6
17.6
17.6
16.6
15.3
14.1
0018
17.5
17.5
17.5
16.4
15.2
14.0
Table 26: Carrier frequency and derating at normal duty (ND) rating - single-phase 200 V class
Normal
Duty
(ND)
Rating
(kW)
Model
Carrier Frequency and Derating (A)
C6-02=1
(2.0kHz)
C6-02=2
(5.0kHz)
C6-02=3
(8.0kHz)
C6-02=4
(10.0kHz)
C6-02=5
(12.5kHz)
C6-02=6
(15.0kHz)
CIPR-
GA50A

CIMR-
VABA

0.1
B001
1.2
1.1
1.0
0.9
0.8
0.6
0001
1.2
1.1
0.9
0.8
0.7
0.6
0.2
B002
1.9
1.9
1.7
1.6
1.4
1.3
0002
1.9
1.8
1.7
1.6
1.5
1.3
0.6
B004
3.5
3.5
3.2
3.0
2.7
2.4
0003
3.3
3.2
3.1
3.0
2.7
2.4
0.8
B006
6.0
6.0
5.4
5.0
4.5
4.0
0006
6.0
5.6
5.3
5.0
4.5
4.0
1.1
B010
9.6
9.1
8.3
7.7
7.1
6.4
0010
9.6
8.8
8.0
7.5
7.0
6.4
1.5
B012
12.2
11.9
11.0
10.4
9.6
8.8
0012
12.0
11.5
11.0
10.4
9.6
8.8
2.2
B018
21.0
19.8
18.1
17.0
15.5
14.1

YASKAWA V1000 Specifications

General

Input Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Frequency	0-400 Hz
Control Method	V/f control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Options	Modbus RTU
Ambient Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20°C to +65°C (-4°F to 149°F)
Humidity	95% (non-condensing)
Cooling Method	Forced Air Cooling
Enclosure	IP20
