YASKAWA V1000

6 Related Drive Parameters
36 YASKAWA ELECTRIC TOBP C730600 60C V1000 Option SI-EN3/V Installation Manual
F7-23 to
F7-32
(3FB to 404)
Dynamic Output
Assembly Parameters
Parameters used in Output Assembly 116. Each parameter
contains a MEMOBUS/Modbus address. The value
received for Output Assembly 116 will be written to this
corresponding MEMOBUS/Modbus address. A
MEMOBUS/Modbus address value of 0 means that the
value received for Output Assembly 116 will not be
written to any MEMOBUS/Modbus register.
Default: 0
F7-33 to
F7-42
(405 to 40E)
Dynamic Input
Assembly Parameters
Parameters used in Input Assembly 166. Each parameter
contains a MEMOBUS/Modbus address. The value sent
for Input Assembly 166 will be read from this
corresponding MEMOBUS/Modbus address. A
MEMOBUS/Modbus address value of 0 means that the
value sent for Input Assembly 166 is not defined by the
user, therefore the option default register value will be
returned.
Refer to Input Assemblies (Drive Produces) on page 41
for definitions of the default MEMOBUS/Modbus
registers.
Default: 0
<1> Set b1-02 = 3 to start and stop the drive with the EtherNet/IP master device using serial communications.
Set b1-01 = 3 to control the frequency reference of the drive via the master device.
<2> Setting this parameter to 3 will cause the drive to continue operation after detecting a fault. Take proper measures
such as installing an emergency stop switch when using setting 3.
<3> Cycle power for setting changes to take effect.
<4> If F7-13 is set to 0, then all IP Addresses (F7-01 to F7-04) must be unique.
<5> Set F7-01 to F7-12 when F7-13 is set to 0.
<6> Default setting differs by drive software version.
1012 to 1015: 0
≥ 1016: 1
<7> Set F7-15 when F7-14 is set to 0 or 2.
<8> The setting values differ by drive software version.
1012 to 1015
Default: 0
Range: 0, 10, 100
≥ 1016
Default: 10
Range: 10, 100
No.
(Addr. Hex)
Name Description Values
