Machine Protection
6-49
îš„Constants and Output Signals
Set the corresponding setting in the multi-function output (H2-01 to H2-05) to output the desired Fref/Fout
Agree signal, Fref/Set Agree signal, or Frequency Detection signal.
L4-04
Speed agree
detection
width (+/−)
Set the speed detection
range in Hz.
0.0 to
20.0
2.0 Hz No A A A A A
Spd Agree
Width +−
User Constant Number Name Function
L4-01 Speed agree detection level
Fref/Set Agree 1
Frequency Detection 1
Frequency Detection 2
L4-02 Speed agree detection width
Fref/Fout Agree 1
Fref/Set Agree 1
Frequency Detection 1
Frequency Detection 2
L4-03 Speed agree detection level (+/-)
Fref/Set Agree 2
Frequency Detection 3
Frequency Detection 4
L4-04 Speed agree detection width (+/-)
Fref/Fout Agree 2
Fref/Set Agree 2
Frequency Detection 3
Frequency Detection 4
Function Setting
Fref/Fout Agree 1 2
Fref/Set Agree 1 3
Frequency Detection 1 4
Frequency Detection 2 5
Fref/Fout Agree 2 13
Fref/Set Agree 2 14
Frequency Detection 3 15
Frequency Detection 4 16
User
Con-
stant
Number
Name
Description
Setting
Range
Factory
Setting
Change
during
Operation
Valid Access Levels
Display
V/f
Control
V/f with
PG
Open-
loop
Vector
1
Flux
Vector
Open-
loop
Vector
2
