Confirmations upon Delivery
1-5
îš‹ Component Names
îš„ Inverters of 15 kW or Less
The external appearance and component names of the Inverter are shown in Fig 1.4. The Inverter with the ter-
minal cover removed is shown in Fig 1.5.
Fig 1.4 Inverter Appearance (15 kW or Less)
Fig 1.5 Terminal Arrangement (15 kW or Less)
Top protective cover
Front cover
Digital Operator
Terminal cover
Mounting hole
Nameplate
Bottom protective cover
Diecast case
Charge indicator
Ground terminal
Control circuit terminals
Main circuit terminals
