Monitor Constants
6-85
Monitor Constants
This section explains the analog monitor and pulse monitor constants.
îš‹ Using the Analog Monitor Constants
This section explains the analog monitor constants.
îš„Related Constants
Con-
stant
Number
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
Display
V/f
V/f
with
PG
Open
Loop
Vector
1
Flux
Vec-
tor
Open
Loop
Vector
2
H4-01
Monitor
selection (ter-
minal FM)
Sets the number of the monitor item
to be output (U1-) from termi-
nal FM.
4, 10 to 14, 25, 28, 34, 39, 40 cannot
be set. 29 to 31 and 41 are not used.
1 to 45
2 NoAAAAA
Terminal FM
Sel
1 to 50
H4-02
Gain (termi-
nal FM)
Sets the multi-function analog out-
put 1 voltage level gain.
Sets whether the monitor item out-
put will be output in multiples of
10 V.
The maximum output from the ter-
minal is 10 V. A meter calibration
function is available.
0.00 to
2.50
1.00 Yes Q Q Q Q Q
Terminal FM
Gain
H4-03
Bias (termi-
nal FM)
Sets the multi-function analog out-
put 1 voltage level bias.
Sets output characteristic up/down
parallel movement as a percentage
of 10 V.
The maximum output from the ter-
minal is 10 V. A meter calibration
function is available.
-10.0 to
+10.0
0.0% Yes A A A A A
Terminal FM
Bias
H4-04
Monitor
selection (ter-
minal AM)
Sets the number of the monitor item
to be output (U1-) from termi-
nal AM.
4, 10 to 14, 25, 28, 34, 39, 40 cannot
be set. 29 to 31 and 41 are not used.
1 to 45
3 NoAAAAA
Terminal AM
Sel
1 to 50
H4-05
Gain (termi-
nal AM)
Set the voltage level gain for multi-
function analog output 2.
Set the number of multiples of 10 V
to be output as the 100% output for
the monitor items. The maximum
output from the terminal is 10 V. A
meter calibration function is avail-
able.
0.00 to
2.50
0.50 Yes Q Q Q Q Q
Terminal AM
Gain
H4-06
Bias (termi-
nal AM)
Sets the multi-function analog out-
put 2 voltage level bias.
Sets output characteristic up/down
parallel movement as a percentage
of 10 V.
The maximum output from the ter-
minal is 10 V. A meter calibration
function is available.
-10.0 to
+10.0
0.0% Yes A A A A A
Terminal AM
Bias
H4-07
Analog out-
put 1 signal
level selec-
tion
Sets the signal output level for
multi-function output 1 (terminal
FM)
0: 0 to +10 V output
1: 0 to ±10 V output
0 or 1 0 No A A A A A
AO Level
Select1
