Yealink CTP18-STD Administrator's Guide

| Getting Started | 20
• Front Panel of VC800 Codec
• Rear Panel of VC800 Codec
Front Panel of VC800 Codec
The LED indicator in front of the camera indicates different camera status.
Related information
LED Indicators of the VCS Devices
Rear Panel of VC800 Codec
Port Name Description
1 Line Out Connect to an audio output device via an audio cable (3.5mm).
2 Line In Connect to an audio input device via an audio cable (3.5mm).
3 USB
• Insert a USB flash drive.
USB flash drive can be used for storing screenshots, recorded
videos or captured packets. If you insert multiple USB flash
drives to the VCS endpoint simultaneously, only the last USB
flash drives you insert can be identified by the endpoint.
• Insert a WF50 Wi-Fi USB Dongle for connecting to Wi-Fi or
providing wireless AP.
• Insert a BT42 Bluetooth USB Dongle for connecting to the
CPW90-BT Bluetooth wireless microphones.
• Insert a PSTN box CPN10 for connecting to the PSTN (Public
Switched Telephone Network).
