Yealink SIP-T46U Administrator's Guide

Phone Provisioning
100
[T42S]features.dnd.enable = 0
Custom configuration file:
Linekey.cfg
linekey.2.type=13
linekey.2.line=1
linekey.2.value = 4603
linekey.2.label=Bill
MAC-Oriented configuration files:
001565b09d886.cfg
account.1.enable = 1
account.1.label = Bill
account.1.display_name = 1023
account.1.auth_name = 1023
account.1.user_name = 1023
account.1.password = 1023
account.1.sip_server.1.address = 10.2.1.199
account.1.sip_server.1.port = 5060
3.
Place the configuration files to the home directory of the provisioning server. For example, D:\TFTP Provision.
4.
Specify the configuration files paths in the boot file as desired. For example,
y000000000000.boot
include:config<tftp:/10.2.5.193/CustomSettings.cfg>
[T46S,T48S]include:config “tftp:/10.2.5.193/Linekey.cfg”
001565b09d886.boot
include:config<tftp:/10.2.5.193/Linekey.cfg>
include:config<tftp:/10.2.5.193/001565b09d886.cfg>
5.
Place the boot files to the home directory of the provisioning server. For example, D:\TFTP Provision.
6.
Reboot the phones to trigger auto provisioning.
For the phone with MAC 001565b09d886, it will download the 001565b09d886.boot file, and then download
Linekey.cfg and 001565b09d886.cfg files referenced in the 001565b09d886.boot file in sequence from the pro-
visioning server.
For the phones except for MAC-specific phone, they will request to download the y000000000000.boot file, and
then request to download the referenced files. The phone-specific configuration file Linekey.cfg only applies to
T46S and T48S phones. The only difference is that T46S and T48S phones will download both the two files since
the exclude mode is disabled by default. The other phones will only download the CustomSettings.cfg file.
For the parameter settings in the CustomSettings.cfg file, the phone-specific parameters will only take effect on the
specific phone models.
The following shows the provisioning flowchart for different phone models with phone-specific settings.

Yealink SIP-T46U Specifications

General

Handset type	Wireless handset
Product type	IP Phone
Product color	Gray
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Expansion module support	Yes
Ethernet LAN (RJ-45) ports	2
Security algorithms	AES, HTTPS, SRTP, TLS
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Front camera	-
AC adapter input voltage	100 - 240 V
Display diagonal	4.3 \
Display resolution	480 x 272 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	16
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Voice codecs	AGC, AJB, AMR-WB, CNG, G.711, G.722, G.723.1, G.726, G.729ab, VAD, iLBC
Number of handles included	1 pc(s)
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	213 mm
Width	244 mm
Height	185 mm
