Yealink SIP-T46U Administrator's Guide

Administrator’s Guide for SIP-T2 Series/T4 Series/T5 Series/CP920 IP Phones
228
3. Click the Convert button.
Then you can find the DOB logo files in the adv directory.
Custom Logo Configuration
The following table lists the parameters you can use to configure the custom logo.
Parameter
phone_setting.lcd_logo.mode <y0000000000xx>.cfg
Description
It configures the logo shown on the LCD screen.
Permitted
Values
0-Off, the phone is not allowed to display a logo.
1-System Logo, the LCD screen will display the system logo.
2-Custom Logo, the LCD screen will display the custom logo (you need to upload a custom logo file to
the IP phone).
Default
0
Supported
Devices
All black-and-white screen phones
Web UI
Features > General Information > Use Logo
Parameter
lcd_logo.url <y0000000000xx>.cfg
Description
It configures the access URL of the custom logo file.
Note: It works only if “phone_setting.lcd_logo.mode” is set to 2 (Custom Logo).

Yealink SIP-T46U Specifications

General

Handset type	Wireless handset
Product type	IP Phone
Product color	Gray
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Expansion module support	Yes
Ethernet LAN (RJ-45) ports	2
Security algorithms	AES, HTTPS, SRTP, TLS
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Front camera	-
AC adapter input voltage	100 - 240 V
Display diagonal	4.3 \
Display resolution	480 x 272 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	16
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Voice codecs	AGC, AJB, AMR-WB, CNG, G.711, G.722, G.723.1, G.726, G.729ab, VAD, iLBC
Number of handles included	1 pc(s)
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	213 mm
Width	244 mm
Height	185 mm
