User Guide for the VC120 Video Conferencing System
34
Idle Screen Display
Idle screen of the display device
If the system starts up, the idle screen will be shown. The following figure is an example of the
idle LCD screen:
Name
Description
Time and Date
The time and date are displayed on the left of the
status bar.
Site name
The site name of the system.
For more information on how to change the site
name, refer to Site Name on page 44.
Status icon
Status icons are displayed in the center of the status
bar. For more information on the status icon, refer to
Icons on Display Device on page 17.
IP address
 LAN: X.X.X.X: Indicates the system has
obtained an IP address.
 Network disconnected: Indicates the system
does not connect to an Ethernet cable. Please
check the Ethernet cable.
