Yealink W60P Administrator's Guide

Configuring Basic Features
223
Anonymous Call
Anonymous call allows the caller to conceal the identity information displayed on the callee’s
screen. The callee’s phone LCD screen prompts an incoming call from anonymity. Anonymous
call is configurable on a per-line basis.
Example of anonymous SIP header:
Via: SIP/2.0/UDP 10.3.20.14:5060;branch=z9hG4bK3074920774
From: "Anonymous" <sip:anonymous@anonymous.invalid>;tag=131654239
To: <sip:1006@10.2.1.48:5060>
Call-ID: 0_288363101@10.3.20.14
CSeq: 1 INVITE
Contact: <sip:1009@10.3.20.14:5060>
Content-Type: application/sdp
Allow: INVITE, INFO, PRACK, ACK, BYE, CANCEL, OPTIONS, NOTIFY, REGISTER, SUBSCRIBE, REFER, PUBLISH,
UPDATE, MESSAGE
Max-Forwards: 70
User-Agent: Yealink W60B 77.81.0.10
Allow-Events: talk,hold,conference,refer,check-sync
P-Preferred-Identity: <sip:1009@10.2.1.48>
Privacy: id
Content-Length: 302
The anonymous call on code and anonymous call off code configured on DECT IP phones are
used to activate/deactivate the server-side anonymous call feature. They may vary on different
servers. Send Anonymous Code feature allows DECT IP phones to send anonymous on/off code
to the server.
Procedure
Anonymous call can be configured using the following methods.
Central Provisioning
(Configuration File)
<MAC>.cfg
Configure anonymous call.
Parameters:
features.provision_anonymous_call_on_g
ui.enable
account.X.anonymous_call
account.X.send_anonymous_code
account.X.anonymous_call_oncode
account.X.anonymous_call_offcode
Web User Interface
Configure anonymous call.
Navigate to:
http://<phoneIPAddress>/servlet?p=acc

Yealink W60P Specifications

General

Mounting	Desk/Wall
Handset type	Wireless handset
Product type	IP Phone
Product color	Black, Silver
Wall mountable	Yes
Standby time	400 h
AC adapter input voltage	100 - 240 V
Battery technology	Lithium
Headset connectivity	3.5 mm
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Maximum indoor range	50 m
Maximum outdoor range	300 m
Lines quantity	- lines
Phonebook capacity	500 entries
Number of handles included	1 pc(s)
Display diagonal	2.4 \
Display resolution	240 x 320 pixels
Voice codecs	AMR-WB, G.722, OPUS
Number of melodies	9
Security algorithms	SRTP, SSL/TLS
Networking standards	IEEE 802.1Q, IEEE 802.1p, IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Volume control	Digital
Keypad number of keys	12
Number of function keys	6
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Harmonized System (HS) code	85171800

Weight and Dimensions

Weight	7500 g
Package depth	95 mm
Package width	196 mm
Package height	205 mm
Package weight	8300 g
Base dimensions	100 x 25.1 x 130 mm
Handset dimensions (WxDxH)	53 x 20.3 x 175 mm
