Yealink W60P Administrator's Guide

Administrator’s Guide for W60P DECT IP Phones
340
Server Domain Name Resolution
If a domain name is configured for a server, the IP address(es) associated with that domain
name will be resolved through DNS as specified by RFC 3263. The DNS query involves NAPTR,
SRV and A queries, which allows the DECT IP phone to adapt to various deployment
environments. The DECT IP phone performs NAPTR query for the NAPTR pointer and transport
protocol (UDP, TCP and TLS), the SRV query on the record returned from the NAPTR for the
target domain name and the port number, and the A query for the IP addresses.
If an explicit port (except 0) is specified, A query will be performed only. If a server port is set to
0 and the transport type is set to DNS-NAPTR, NAPTR and SRV queries will be tried before
falling to A query. If no port is found through the DNS query, 5060 will be used.
The following details the procedures of DNS query for the DECT IP phone to resolve the
domain name (e.g., yealink.pbx.com) of working server into the IP address, port and transport
protocol.
NAPTR (Naming Authority Pointer)
First, the DECT IP phone sends NAPTR query to get the NAPTR pointer and transport protocol.
Example of NAPTR records:
order pref flags service regexp replacement
IN NAPTR 90 50 "s" "SIP+D2T" "" _sip._tcp.yealink.pbx.com
IN NAPTR 100 50 "s" "SIP+D2U" "" _sip._udp.yealink.pbx.com
Parameters are explained in the following table:
Parameter
Description
order
Specify preferential treatment for the specific record. The order is
from lowest to highest, lower order is more preferred.
pref
Specify the preference for processing multiple NAPTR records with
the same order value. Lower value is more preferred.
Flags
The flag “s” means to perform an SRV lookup.
service
Specify the transport protocols:
SIP+D2U: SIP over UDP
SIP+D2T: SIP over TCP
SIP+D2S: SIP over SCTP
SIPS+D2T: SIPS over TCP
regexp
Always empty for SIP services.
replacement
Specify a domain name for the next query.
The DECT IP phone picks the first record because its order of 90 is lower than 100. The pref
parameter is unimportant as there is no other record with order 90. The flag “s” indicates

Yealink W60P Specifications

General

Mounting	Desk/Wall
Handset type	Wireless handset
Product type	IP Phone
Product color	Black, Silver
Wall mountable	Yes
Standby time	400 h
AC adapter input voltage	100 - 240 V
Battery technology	Lithium
Headset connectivity	3.5 mm
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Maximum indoor range	50 m
Maximum outdoor range	300 m
Lines quantity	- lines
Phonebook capacity	500 entries
Number of handles included	1 pc(s)
Display diagonal	2.4 \
Display resolution	240 x 320 pixels
Voice codecs	AMR-WB, G.722, OPUS
Number of melodies	9
Security algorithms	SRTP, SSL/TLS
Networking standards	IEEE 802.1Q, IEEE 802.1p, IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Volume control	Digital
Keypad number of keys	12
Number of function keys	6
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Harmonized System (HS) code	85171800

Weight and Dimensions

Weight	7500 g
Package depth	95 mm
Package width	196 mm
Package height	205 mm
Package weight	8300 g
Base dimensions	100 x 25.1 x 130 mm
Handset dimensions (WxDxH)	53 x 20.3 x 175 mm
