NeoGate TG Series User Manual
14/62
IP Address2 Set the second IP Address for NeoGate TG
Subnet Mask2 Set the second subnet mask for NeoGate TG
5.1.2 VLAN Settings
A VLAN (Virtual LAN) is a logical local area network (or LAN) that extends
beyond a single traditional LAN to a group of LAN segments, given specific
configurations.
Note:
NeoGate TG is not the VLAN server, a 3-layer switch is still needed, please
configure the VLAN information there first, then input the details in NeoGate TG,
so that the packages via NeoGate TG will be added the VLAN label before
sending to that switch.
Figure 5-2
Items
Description
NO.1
Click the NO.1 you can edit the first VLAN over LAN
VLAN Number
The VLAN Number is a unique value you assign to each
VLAN on a single device
VLAN IP Address
Set the IP Address for NeoGate TG VLAN over LAN.
VLAN Subnet Mask
Set the Subnet Mask for NeoGate TG VLAN over LAN.
Default Gateway Set the Default Gateway for NeoGate TG VLAN over LAN
NO.2 Click the NO.2 you can edit the first VLAN over LAN.
VLAN Number
.The VLAN Number is a unique value you assign to each
VLAN on a single device.
VLAN IP Address
Set the IP Address for NeoGate TG VLAN over LAN.
VLAN Subnet Mask Set the Subnet Mask for NeoGate TG VLAN over LAN.
Default Gateway Set the Default Gateway for NeoGate TG VLAN over LAN.
