NeoGate TG Series User Manual
23/62
Figure 5-14
Name A name for this rule, e.g. “HTTP”.
Description
Simple description for this rule. E.g.: Accept the specific host to
access the web interface for configuration.
The protocols for this rule.
Port
Initial port should be on the left and end port should be on the
right. The end port must be equal to or greater than start port.
IP
The IP address for this rule. The format of IP address is: IP/mask
Ex: 192.168.5.100/255.255.255.255 for IP 192.168.5.100
Ex:192.168.5.0/255.255.255.0 for IP from 192.168.5.0 to
192.168.5.255 .
Address
The format of MAC Address is XX:XX:XX:XX:XX:XX, X means 0~9
or A~F in hex, the A~F are not case sensitive.
Action
Accept: Accept the access from remote hosts.
Drop: Drop the access from remote hosts.
Ignore: Ignore the access.
Note: The MAC address will be changed when it’s a remote device, so it will
not be working to filter using MAC for remote devices.
5.2.5 IP Blacklist
You can set some packets accept speed rules here. When a IP address which
hasn’t been accepted in common rules sends packets faster than the allowed
speed, it will be set as black IP address and blocked automatically.
