:CALCulate:PARameter[:CATegory]:LED
Function Sets/queries parameters for the LED analysis
function.
Syntax
:CALCulate:PARameter[:CATegory]:LED
<wsp><item>,<paramater>,<data>
:CALCulate:PARameter[:CATegory]:LED
?<wsp><item>,<paramater>
<item> = Analytical item that sets parameter(s)
<parameter> = Parameter to be set
<data> = Setting data
<item> <parameter> <data>
SWIDth ALGO ENVelope|THResh|
RMS|PKRMs
TH <NRf>[DB]
TH2 <NRf>[DB]
K <NRf>
MFIT OFF|ON|0|1
MDIFf <NRf>[DB]
MWAVelength ALGO ENVelope|THResh|
RMS|PKRMs
TH <NRf>[DB]
TH2 <NRf>[DB]
K <NRf>
MFIT OFF|ON|0|1
MDIFf <NRf>[DB]
TPOWer OFFSet <NRf>[DB]
Example
:CALCULATE:PARAMETER:LED
SWIDTH,ALGO,THRESHh
:CALCULATE:PARAMETER:LED?
SWIDTH,ALGO -> THR
:CALCULATE:PARAMETER:LED TPOWER,
OFFSET,1.0DB :CALCULATE:PARAMETER:
LED? TPOWER,OFFSET ->
+1.00000000E+000
Explanation • If a non-existing parameter is used for a
combination, an execution error occurs
(a combination of SWIDth and OFFSet, etc.).
• This is a sequential command.
:CALCulate:PARameter[:CATegory]:NF:A
ALGo
Function Sets/queries the measurement algorithm
applied to ASE level measurements made by
the NF analysis function.
Syntax
:CALCulate:PARameter[:CATegory]:NF:
AALGo<wsp><algorhythm>
:CALCulate:PARameter[:CATegory]:NF:
AALGo?
<algorhythm> = Measurement algorithm
AFIX: AUTO FIX
MFIX: MANUAL FIX
ACENter: AUTO CENTER
MCENter: MANUAL CENTER
Response 0 = AUTO FIX
1 = MANUAL FIX
2 = AUTO CENTER
3 = MANUAL CENTER
Example
:CALCULATE:PARAMETER:NF:AALGO MFIX
:CALCULATE:PARAMETER:NF:AALGO? -> 1
Explanation • With the AQ6373/AQ6373B, the command is
invalid.
• This is a sequential command.
:CALCulate:PARameter[:CATegory]:NF:F
ALGo
Function Sets/queries the fitting function during
level measurement applied to ASE level
measurements made by the NF analysis
function.
Syntax
:CALCulate:PARameter[:CATegory]:NF:
FALGo<wsp><algorhythm>
:CALCulate:PARameter[:CATegory]:NF:
FALGo?
<algorhythm> = Fitting function
LINear: LINEAR
GAUSs: GAUSS
LORenz: LORENZ
3RD: 3RD POLY
4TH: 4YH POLY
5TH: 5TH POLY
Response 0 =LINEAR
1 = GAUSS
2 = LORENZ
3 = 3RD POLY
4 = 4YH POLY
5 = 5TH POLY
Example
:CALCULATE:PARAMETER:NF:FALGO GAUSS
:CALCULATE:PARAMETER:NF:FALGO? -> 1
Explanation • With the AQ6373/AQ6373B, the command is
invalid.
• This is a sequential command.
7.6 Instrument-Specific Commands
