:CALCulate:PARameter[:CATegory]:NF:
TH
Function Sets/queries the threshold level of channel
detection for the NF analysis function.
Syntax
:CALCulate:PARameter[:CATegory]:NF:
TH<wsp><NRf>[DB]
:CALCulate:PARameter[:CATegory]:NF:TH?
<NRf> = Threshold level [dB]
Example
:CALCULATE:PARAMETER:NF:TH 20.00DB
:CALCULATE:PARAMETER:NF:TH->
+2.00000000E+001
Explanation • With the AQ6373/AQ6373B, the command is
invalid.
• This is a sequential command.
:CALCulate:PARameter[:CATegory]:NF:R
BWidth
Function Sets/queries the method for calculating the
resolution value of the NF computation.
Syntax
:CALCulate:PARameter[:CATegory]:NF:
RBWidth<wsp>MEASured|CAL|0|1
:CALCulate:PARameter[:CATegory]:NF:
RBWidth?
MEASured | 0 Use the value determined from
the waveform using THRESH
3dB analysis.
CAL | 1 Use the actual resolution value
stored in the instrument .
Response 0=MEASURED, 1=CAL
Example
:CALCULATE:PARAMETER:NF:RBWIDTH
MEASURED
:CALCULATE:PARAMETER:NF:RBWIDTH?
-> 0
Explanation • With the AQ6373/AQ6373B, the command is
invalid.
• This is a sequential command.
:CALCulate:PARameter[:CATegory]:NF:S
NOise
Function Sets/queries whether Shot Noise is included in
the NF computation
Syntax
:CALCulate:PARameter[:CATegory]:NF:
SNOise<wsp>OFF|ON|0|1
:CALCulate:PARameter[:CATegory]:NF:
SNOise?
OFF | 0 Shot Noise not included in the
NF computation
ON | 1 Shot Noise included in the NF
computation
Response 0=OFF, 1=ON
Example
:CALCULATE:PARAMETER:NF:SNOISE OFF
:CALCULATE:PARAMETER:NF:SNOISE?-> 0
Explanation • With the AQ6373/AQ6373B, the command is
invalid.
• This is a sequential command.
:CALCulate:PARameter[:CATegory]:NOTC
h:K
Function Sets/queries the magnification of the notch
width analysis function.
Syntax
:CALCulate:PARameter[:CATegory]:NOT
Ch:K<wsp><NRf>[DB]
:CALCulate:PARameter[:CATegory]:NOT
Ch:K?
<NRf> = Magnification
Example
:CALCULATE:PARAMETER:NOTCH:K 2.00
:CALCULATE:PARAMETER:NOTCH:K?->
+2.00000000E+000
Explanation This is a sequential command.
:CALCulate:PARameter[:CATegory]:NOTC
h:TH
Function Sets/queries the threshold value for the notch
width analysis function.
Syntax
:CALCulate:PARameter[:CATegory]:NOT
Ch:TH<wsp><NRf>[DB]
:CALCulate:PARameter[:CATegory]:NOT
Ch:TH?
<NRf> = Threshold level [dB]
Example
:CALCULATE:PARAMETER:NOTCH:
TH 3.00DB
:CALCULATE:PARAMETER:NOTCH:TH?->
+3.00000000E+000
Explanation This is a sequential command.
:CALCulate:PARameter[:CATegory]:NOTC
h:TYPE
Function Sets/queries the analysis direction of the notch
width analysis function.
Syntax
:CALCulate:PARameter[:CATegory]:NOT
Ch:TYPE<wsp>PEAK|BOTTom|0|1
:CALCulate:PARameter[:CATegory]:NOT
Ch:TYPE?
PEAK: Performs analysis using the peak
level of a waveform as a reference.
BOTTom: Performs analysis using the bottom
level of a waveform as a reference.
Response 0 = PEAK, 1 = BOTTom
Example
:CALCULATE:PARAMETER:NOTCH:
TYPE BOTTOM
:CALCULATE:PARAMETER:NOTCH:TYPE? ->
1
Explanation This is a sequential command.
:CALCulate:PARameter[:CATegory]:PMD:
TH
Function Sets/queries the threshold value for the PMD
analysis function.
Syntax
:CALCulate:PARameter[:CATegory]:PMD
:TH<wsp><NRf>[DB]
:CALCulate:PARameter[:CATegory]:PMD
:TH?
<NRf> = Threshold level [dB]
Explanation
:CALCULATE:PARAMETER:PMD:TH 10.00DB
:CALCULATE:PARAMETER:PMD:TH?->
+1.00000000E+001
7.6 Instrument-Specific Commands
