YOKOGAWA AQ6370C User Manual

7-67
IM AQ6370C-17EN
Remote Commands
1
2
3
4
5
6
7
8
App
Index
:CALCulate:PARameter[:CATegory]:WFBo
ttom
Function Sets/queries parameters for the WDM FILTER-
BTM analysis function.
Syntax
:CALCulate:PARameter[:CATegory]:WFB
ottom<wsp><item>,<paramater>,<data>
:CALCulate:PARameter[:CATegory]:WFB
ottom?<wsp><item>,<paramater>
<item> = Analytical item that sets parameter(s)
<parameter> = Parameter to be set
<data> = Data to be set
<item> <parameter> <data>
NWAVelength ALGO BOTtom|NPEak|
NBOTtom|
GFIT|GRID
MDIFf <NRf>[DB]
TH <NRf>[DB]
TBANd <NRf>[M]
BWAVelength SW OFF|ON|0|1
CWAVelength SW OFF|ON|0|1
ALGO NPEak|NBOTtom
TH <NRf>[DB]
SBANd SW OFF|ON|0|1
TH <NRf>[DB]
EBANd SW OFF|ON|0|1
TH <NRf>[DB]
TBANd <NRf>[M]
RIPPle SW OFF|ON|0|1
TBANd <NRf>[M]
XTALk SW OFF|ON|0|1
SPACing <NRf>[M]
TBANd <NRf>[M]
Example
:CALCULATE:PARAMETER:WFBOTTOM
NWAY,ALGO,NPEAK
:CALCULATE:PARAMETER:WFBOTTOM?
NWAY,ALGO -> NPE:CALCULATE:
PARAMETER:WFBOTTOM BWAVELENGTH,SW,
OFF
:CALCULATE:PARAMETER:WFBOTTOM?
BWAVELENGTH,SW -> 0
Explanation • If a non-existing parameter is used for a
combination, an execution error occurs (a
combination of NWAVelength and SPACing,
etc.).
• With the AQ6373/AQ6373B, the command is
invalid.
• This is a sequential command.
:CALCulate:PARameter[:CATegory]:WFPe
ak
Function Sets/queries parameters for the WDM FILTER-
PEAK analysis function.
Syntax
:CALCulate:PARameter[:CATegory]:WFP
eak<wsp><item>,<paramater>,<data>
:CALCulate:PARameter[:CATegory]:WFP
eak?<wsp><item>,<paramater>
<item> = Analytical item that sets parameter(s)
<parameter> = Parameter to be set
<data> = Data to be set
<item> <parameter> <data>
NWAVelength ALGO PEAK|MEAN|GFIT|
GRID
MDIFf <NRf>[DB]
TH <NRf>[DB]
TBANd <NRf>[M]
PWAVelength SW OFF|ON|0|1
CWAVelength SW OFF|ON|0|1
TH <NRf>[DB]
SBANd SW OFF|ON|0|1
TH <NRf>[DB]
PBANd SW OFF|ON|0|1
TH <NRf>[DB]
TBANd <NRf>[M]
RIPPle SW OFF|ON|0|1
TBANd <NRf>[M]
XTALk SW OFF|ON|0|1
SPACing <NRf>[M]
TBANd <NRf>[M]
Example
:CALCULATE:PARAMETER:WFPEAK
NWAY,ALGO,PEAK
:CALCULATE:PARAMETER:WFPEAK?
NWAY,ALGO -> PEAK
:CALCULATE:PARAMETER:WFPEAK
BWAVELENGTH,SW,OFF
:CALCULATE:PARAMETERWFPEAK?
BWAVELENGTH,S -> 0
Explanation • If a non-existing parameter is used for a
combination, an execution error occurs (a
combination of NWAVelength and SPACing, etc.).
• With the AQ6373/AQ6373B, the command is
invalid.
• This is a sequential command.
:CALCulate:PARameter:COMMon:MDIFf
Function Sets/queries the peak-bottom difference
parameter of channel detection used in the
analysis function.
Syntax
:CALCulate:PARameter:COMMon:MDIFf<w
sp><NRf>[DB]
:CALCulate:PARameter:COMMon:MDIFf?
Example
:CALCULATE:PARAMETER:COMMON:
MDIFF 3.00DB
:CALCULATE:PARAMETER:COMMON:MDIFF->
+3.00000000E+000
Explanation This is a sequential command.
7.6 Instrument-Specific Commands
