• DRIFT (GRID)
<ch num>,<ref wl>,<center wl>,<wl diff max>,<wl dif
f min>,<ref lvl>, <peak lvl>, <lvl
diff max>, <lvl diff min>,...
EDFA-NF
<ch num>,<center wl>,<input lvl>,<output lvl>,<ase lvl>, <resoln>, <gain>, <nf>,...
FILTER-PK
<peak wl>,<peak lvl>,<center wl>,<spec wd>,<l-xtalk>,<r-xtalk>, <ripple>
FILTER-BTM
<btm wl>, <btm lvl>, <center wl>, <notch wd>, <l-xtalk>, <r-xtalk>
WDM FIL-PK
<ch num>, <nominal wl>, <peak wl>, <peak lvl>, <xdb wd>, <center wl>, <xdb sb>,
<xdb pb>, <ripple>, <l-xtalk>, <r-xtalk>,...
* Items with SW set to OFF are also output.
WDM FIL-BTM
<ch num>, <nominal wl>, <btm wl>, <btm lvl>, <xdb ntwd>, <center wl>, <xdb sb>,
<xdb eb>, <ripple>, <l-xtalk>, <r-xtalk>,...
* Items with SW set to OFF are also output.
COLOR
<dominant wl>,<x col>,<y col>,<z col>
7.7 Output Format for Analysis Results
