7-100

IM AQ6370C-17EN

List of Abbreviations of Data Output Using the CALCulate:DATA? Command

Abbreviation Description Format Output Unit

<center wl> Center wavelength <NRf> m / Hz

<spec wd> Spectrum width <NRf> m / Hz

<mode num> Mode number <integer>

<notch wd> Notch width <NRf> m / Hz

<peak wl> Peak wavelength <NRf> m / Hz

<peak lvl> Peak level <NRf> dBm

<2nd peak wl> 2nd peak wavelength <NRf> m / Hz

<2nd peak lvl> 2nd peak level <NRf> dB

<delta wl> Wavelength difference <NRf> m / Hz

<delta lvl> Level difference <NRf> dB

<mode ofst> Mode offset <NRf> m / Hz

<smsr> SMSR value <NRf> dB

<smsr(L)> SMSR value (shorter wavelength side) <NRf> dB

<smsr(R)> SMSR value (longer wavelength side) <NRf> dB

<mode ofst(L)> Mode offset (shorter wavelength side) <NRf> m/Hz

<mode ofst(R)> Mode offset (longer wavelength side) <NRf> m/Hz

<2nd peak wl(L)>

Second peak wavelength (shorter wavelength side)

<NRf> m/Hz

<2nd peak wl(R)> Second peak wavelength (longer wavelength side) <NRf> m/Hz

<2nd peak lvl(L)> Second peak level (shorter wavelength side) <NRf> dB

<2nd peak lvl(R)> Second peak level (longer wavelength side) <NRf> dB

<delta wl(L)> Wavelength difference (shorter wavelength side) <NRf> m/Hz

<delta wl(R)> Wavelength difference (longer wavelength side) <NRf> m/Hz

<delta lvl(L)> Level difference (shorter wavelength side) <NRf> dB

<delta lvl(R)> Level difference (longer wavelength side) <NRf> dB

<power> Power value <NRf> dB/W

<total pow> Total power value <NRf> dB / W

<mode num> Mode number <integer>

<left mode peak> Mode peak frequency (left) <NRf> Hz

<right mode peak> Mode peak frequency (right) <NRf> Hz

<pmd> PMD value <NRf> ps

<ch num> Channel number <integer>

<offset wl> Offset wavelength <NRf> m / Hz

<offset lvl> Offset level <NRf> dB

<noise> Noise level <NRf> dBm / NBW

<snr> SNR value <NRf> dB

<grid wl> Grid wavelength <NRf> m / Hz

<rel wl> Relative wavelength <NRf> m / Hz

<wl diff max> Wavelength difference (max.) <NRf> m / Hz

<wl diff min> Wavelength difference (min.) <NRf> m / Hz

<ref lvl> Relative level <NRf> dB

<lvl diff max> Level difference (max.) <NRf> dB

<lvl diff min> Level difference (min.) <NRf> dB

<input lvl> Input level <NRf> dBm

<output lvl> Output level <NRf> dBm

<ase lvl> ASE level <NRf> dBm / RES

<resoln> Measurement resolution <NRf> m

<gain> Gain <NRf> dB

<nf> NF value <NRf> dB

<l-xtalk> Crosstalk value (left) <NRf> dB

<r-xtalk> Crosstalk value (right) <NRf> dB

<ripple> Ripple width <NRf> m / Hz

7.7 Output Format for Analysis Results
