LEVEL
The following command is not available on the AQ6375/AQ6375B if the horizontal axis is
set to Wavenumber mode.
LEVEL UNIT ###### #####: dBm, dBm/nm
Program Command Description Instrument models on which the
command is valid, parameter ranges,
and supported variables.
REFERENCE LEVEL
***.*dBm
Sets the reference level valueused
for LOG scaling.
–90.0 to 30.0dBm (0.1 step)
REFERENCE LEVEL
***.*##
Sets the reference level value
used for LIN scaling
1.00pW to 1000mW
(1.00to9.99[pW,nW,μW,mW]:0.01
step
10.0to99.9(100)[pW,nW,μW,(mW)]
:0.1 step
100to999[pW,nW,μW,mW]:1
step)
##is,pW,nW,μW,mW(selectoneof
the above)
REFERENCE LEVEL
@@@@@
Sets the value of variable
@@@@@ to the reference level
value
AQ6370C/AQ6370D
@@@@@: E
1
, G, H, I, J, K, O
1
, P,
Q, R,S, T
1
, U
1
, V
1
, X, Y, Z, LM, L1,
L2, L(CH), PKLVL, WDMLVL(CH),
FLVI(CH), NFLVO(CH),
NFASELV(CH), MKPWR, LAM1,
LAM2, LAM3, LAM4
LEVEL SCALE **.*dB/D Sets a level scale value. 0 (LINEAR), 0.1 to 10.0dB/DIV
(0.1 step)
LEVEL SCALE
@@@@@
Sets the value of variable
@@@@@ to the level scale
@@@@@: E
1
, G, H, I, J, K, O
1
, P, Q,
R,S, T
1
, U
1
, V
1
, X, Y, Z, L2-L1, SMSR,
SMSR2, WDMSNR(CH), NFNF(CH),
LAM2-LAM1, LAM4-LAM3
BASE LEVEL **** Lower value for linear scale setting.
Use units set under REF LEVEL.
If exceeds 90% of upper units of
scale, execution error results
0 to 900 (0.1 step)
PEAK->REF LEVEL Sets peak level of the waveform
on the active trace to the
reference level value
AUTO REF LEVEL ### Executes after each sweep
finishes. Selects ON/OFF for the
<PEAK→REFLEVEL>function.
###: ON/OFF
LEVEL UNIT ###### Sets the unit of a level scale. ###: dBm, dBm/nm
Y SCALE DIVISION
##DIV
Sets the level scale division. ##: 8, 10, 12
1: Generalized variables E, O, T, U, and V are valid only for the AQ6370C/AQ6370D/
AQ6375B.
Note
For the AQ6375/AQ6375B, dBm/nm and W/nm cannot be selected for LEVEL UNIT when the
horizontal axis is wavenumber. (DBM/NM parameters cannot be set. )
8.3 Program Function Commands
To Next Page
