YOKOGAWA AQ6370C User Manual

8-23
IM AQ6370C-17EN
Program Function
1
2
3
4
5
6
7
8
App
Index
Program Command Description Instrument models on which the
command is valid, parameter
ranges, and supported variables.
REF LEVEL POSITION
**DIV
Sets the position of the reference
level on the level scale
0 to 12 (1 step)
SUB SCALE LOG
**.*dB/D
Sets the sub scale value used for
LOG scaling.
0.1 to 10.0dB/DIV (0.1 step)
SUB SCALELIN *.***/D Sets the sub scale value used for
LIN scaling.
0.005 to 1.250 (0.005 step)
SUB SCALE **.*dB/km Sets the sub scale value used for
dB/km scaling.
0.1 to 10.0 (0.1 step)
SUB SCALE **.*%/D Sets the sub scale value used for
%D scaling.
0.5 to 125.0 (0.1 step)
OFFSET LEVEL **.*dB Sets the sub scale offset value
used for LOG scaling
–99.9 to 99.9 (0.1 step)
OFFSET LEVEL ***.*dB/
km
Sets the sub scale offset value
used for dB/km scaling
–99.9 to 99.9 (0.1 step)
SCALE MINIMUM **.** Sets the lower sub scale value
used for linear scaling.
000 to 12.50 (0.01 step)
SCALE MINIMUM ***.*% Sets the lower sub scale value
used for &D scaling.
0.0 to 1250.0 (0.1 step)
LENGTH **.***km Sets fiber length. 0.001 to 99.999 (0.001 step)
AUTO SUB SCALE ### Automatically sets the sub scale
from the calculated trac e waveform
###: ON/OFF
SUB REF LEVEL
POSITION **DIV
Sets the position of the reference
level on the sub level scale
0 to 12 (1 step)
8.3 Program Function Commands
