SETUP
Program Command Description Instrument models on which the
command is valid, parameter
ranges, and supported variables.
RESOLUTION WL
*.****nm
Sets the wavelength resolution. AQ6370C/AQ6370D
0.020 to 2.000 (1-2-5 step)
AQ6373/AQ6373B
0.010 to 10.000 (1-2-5 step)
AQ6375/AQ6375B
0.050 to 2.000 (1-2-5 step)
RESOLUTION WL
@@@@@
Sets the value of variable @@@@@
to the wavelength resolution
@@@@@: E
1
, G, H, I, J, K, O
1
,
P, Q, R, S, T
1
, U
1
, V
1
, X, Y, Z,
W2-W1, SPWD
RESOLUTION FREQ
***GHz
Sets the frequency resolution. AQ6370C/AQ6370D
4 to 400 (1-2-4 step)
AQ6373/AQ6373B
2 to 2000 (1-2-4 step)
AQ6375/AQ6375B
10 to 400 (1-2-4 step)
RESOLUTION
FREQ@@@@@
Sets the value of variable @@@@@
to the frequency resolution
@@@@@: E
1
, G, H, I, J, K, O
1
,
P, Q, R, S, T
1
, U
1
, V
1
, X, Y, Z,
W2-W1, SPWD, WAM2-WAM1,
WAM4-WAM2
RESOLUTION WNUM
*.****cm
-1
Sets the wavenumber resolution.(only
for AQ6375)
AQ6375/AQ6375B
0.10 to 5.00 (1-2-5 step)
RESOLUTION WNUM
@@@@@
Sets the value of variable @@@@@
to the wavenumber resolution(only for
AQ6375)
@@@@@: G, H, I, J, K, P, Q, R,
S, X, Y, Z, W2-W1, SPWD
SENS NORMAL/HOLD Sets the measuring sensitivity to
NORMAL/HOLD
SENS NORMAL/AUTO Sets the measuring sensitivity to
NORMAL/AUTO
SENS NORMAL Sets measuring sensitivity to NORMAL
SENS MID Sets measuring sensitivity to MID.
SENS HIGH1 Sets measuring sensitivity to HIGH1. AQ6370C/AQ6370D
SENS HIGH1/CHOP Sets measuring sensitivity to HIGH1/
CHOP
AQ6375/AQ6375B
SENS HIGH2 Sets measuring sensitivity to HIGH2. AQ6370C/AQ6370D
SENS HIGH2/CHOP Sets measuring sensitivity to HIGH2/
CHOP
AQ6375/AQ6375B
SENS HIGH3 Sets measuring sensitivity to HIGH3 AQ6370C/AQ6370D
SENS HIGH3/CHOP Sets measuring sensitivity to HIGH3/
CHOP
AQ6375/AQ6375B
CHOPPER ###### Switches chopper mode. AQ6370C /AQ6370D/AQ6373/
AQ6373B
AVERAGE TIMES *** Sets the number of averaging times. 1 to 999 (1 step)
AVERAGE TIMES @ Sets the number of averaging times to
the value of variable
@: E
1
, G, H, I, J, K, O
1
, P, Q, R, S,
T
1
, U
1
, V
1
, X, Y, Z, M, N
SAMPLING POINT
AUTO ###
Sets sampling points per sweep
automatically.
###: ON/OFF
SAMPLING POINT ***** Sets sampling points per sweep. 101 to 50001 (1 step)
SAMPLING POINT @ Sets the sampling points to the variable
@.
@: E
1
, G, H, I, J, K, O
1
, P, Q, R, S,
T
1
, U
1
, V
1
, X, Y, Z, M, N
SAMPLING INTERVAL
*.****nm
Sets the measurement sampling
interval per sweep
AQ6370C/AQ6370D/AQ6373/
AQ6373B
0.001 to SPAN/101 (0.001 step)
AQ6375/AQ6375B
0.002 to SPAN/101 (0.001 step)
SAMPLING INTERVAL
@
Sets the sampline interval per sweep
to the value of variable @.
@: E
1
, G, H, I, J, K, O
1
, P, Q, R, S,
T
1
, U
1
, V
1
, X, Y, Z, W2-W1, SPWD,
WAM2-WAM1, WAM4-WAM3
MEASURE
WAVELENGTH AIR
Sets the measurement wavelength to
an air wavelength
8.3 Program Function Commands
