Setting the Command Format
8.
Perform these steps if you will use AQ6317 commands. Press the COMMAND
FORMAT soft key. The command format setting menu is displayed.
9.
Normally, you will enter AQ6370C, AQ6370D, AQ6373, AQ6373B, AQ6375 or
AQ6375B. If you wish to use AQ6317 commands, enter AQ6317.
Explanation
The settings below are used when entering the settings that can be entered using the
instrument’s panel keys from a controller, or when outputting settings or waveform data
to the controller.
GP-IB Address Settings
When in Addressable mode, set the instrument’s address within the following range.
0 to 30
Each device that can be connected via GP-IB has its own unique GP-IB address. This
address allows each device to be distinguished from other devices. Therefore, when
connecting the instrument to a PC or other device, make sure not to set the same
address on the instrument as any of the other devices.
Note
• Do not change an address while the controller or other devices are using GP-IB.
• Set addresses other than those used by the GP-IB2 port.
Command Format Settings
Normally, you will enter AQ6370C, AQ6370D, AQ6373, AQ6373B, AQ6375 or AQ6375B
mode.
If you wish to use the commands of the AQ6317 (another product in the series), enter
AQ6317. See the appendix for AQ6317 commands that are compatible with the AQ6317.
Note
Controller functions and TLS address settings are entered when controlling an external device
using the GP-IB2 port. These settings are invalid for the GP-IB1 port.
2.4 Setting the GP-IB Address
To Next Page
