YOKOGAWA AQ6370C

8-50
IM AQ6370C-17EN
Variable Calculations
Program Command Description Parameter Rng, Avail Variables
@ = ********** ### Substitutes a value into variable @.For
**********, a real number of 10 or fewer
digits can be specified, including a sign
and the decimal point.
@: E
1
, G, H, I, J, K, O
1
, P, Q, R, S,
T
1
, U
1
, V
1
, X, Y, Z, CH
**********: –999999999 to
9999999999 (1 step)
###: nm, dB, dBm, pW, nW, µW,
mW, W, THz, cm
-1
(AQ6375/
AQ6375B), ’ ’ (without units)
@ = # + ********** Adds value ********** to variable #
and substitutes the value into variable
@.********* can be specified with a real
number of 10 or fewerdigits, including
a sign and the decimal point. By
specifying a negative value, you can
cause subtraction to be made from
variable #.
@, #: E
1
, G, H, I, J, K, O
1
, P, Q, R, S,
T
1
, U
1
, V
1
, X, Y, Z, CH
**********: –999999999 to
9999999999 (1 step)
@ = @@@@@ Copies the contents of variable
@@@@@ to variable @.
@: E
1
, G, H, I, J, K, O
1
, P, Q, R, S,
T
1
, U
1
, V
1
, X, Y, Z, CH
@@@@@: E
1
, G, H, I, J, K,
O
1
, P, Q, R, S, T
1
, U
1
, V
1
, X,
Y, Z, WM, W1, W2, W2-W1,
W(CH), LM, L1, L2, L2-L1,
L(CH), SPWD, MEANWL, PKWL,
PKLVL, MODN, GONO, SMSR,
WDMCHN, WDMWL(CH),
WDMLVL(CH), WDMSNR(CH),
NFCHN, NFWL(CH), NFLVLI(CH),
NFLVLO(CH), NFASELV(CH),
NFGAIN(CH), NFNF(CH),
MKPWR, PMD, M, N, CH,
WAM1, WAM2, WAM3, WAM4,
WAM2-WAM1, WAM4-WAM3,
LAM1, LAM2, LAM3, LAM4,
LAM2-LAM1, LAM4-LAM3
@ = @@@@@ +
#####
@ = @@@@@ -
#####
@ = @@@@@ *
#####
@ = @@@@@ /
#####
Performs addition, subtraction,
multiplication, and/or division between
variables.
####: E
1
, G, H, I, J, K, O
1
, P, Q, R,
S, T
1
, U
1
, V
1
, X, Y, Z, CH
@@@@@: E
1
, G, H, I, J, K, O
1
, P,
Q, R,S, T
1
, U
1
, V
1
, X, Y, Z, WM, W1,
W2, W2-W1, W(CH), LM, L1, L2,
L2-L1, L(CH), SPWD, MEANWL,
PKWL, PKLVL, MODN, GONO,
SMSR, WDMCHN, WDMWL(CH),
WDMLVL(CH), WDMSNR(CH),
NFCHN, NFWL(CH), NFLVLI(CH),
NFLVLO(CH), NFASELV(CH),
NFGAIN(CH), NFNF(CH),
MKPWR, PMD, M, N, CH,
WAM1, WAM2, WAM3, WAM4,
WAM2-WAM1, WAM4-WAM3,
LAM1, LAM2, LAM3, LAM4,
LAM2-LAM1, LAM4-LAM3
@$ = @$ Copies string variable @$ to
stringvariable @.
@$: A$, B$, C$, D$
@$ = MID
(@$, @, @)
Substitutes @’s worth of characters in
the string that is distant from the start of
character variable @$ by the number of
characters in the numerical variable @
into character variable @$.
@: E
1
, G, H, I, J, K, O
1
, P, Q, R, S,
T
1
, U
1
, V
1
, X, Y, Z
@$: A$, B$, C$, D$
@$ = ’---56 chars---’ Substitutes string to character variable
@$. (56 chars max)
@$: A$, B$, C$, D$
@$ =@$+@$ Substitutes the character string
obtained by concatenating character
variable @$ and character variable @$
into character variable @$.
AQ6370C/AQ6370D/AQ6375B
@$: A$: B$: C$: D$
8.3 Program Function Commands
