Condition Judgement
Program Command Description Parameter Rng, Avail Variables
IF F1 <= @@@@@
<= F2 GOTO ***
Value of variable @@@@@ is F1
or greaterIf less than F2, jumps to
line ***
@@@@@: E
1
, G, H, I, J, K, O
1
,
P, Q, R, S, T
1
, U
1
, V
1
, X, Y, Z,
WM, W1, W2, W2-W1, W(CH),
LM, L1, L2, L2-L1, L(CH), SPWD,
MEANWL, PKWL, PKLVL, MODN,
GONO, SMSR, SMSR2, WDMCHN,
WDMWL(CH), WDMLVL(CH),
WDMSNR(CH), FNCHN, NFWL(CH),
NFLVL(CH), NFLVI(CH), NFLVO(CH),
NFASELV(CH), NFGAIN(CH),
NFNF(CH), MKPWR, PMD, M, N,
CH, A$, B$, C$, D$, FILE$, WAM1,
WAM2, WAM3, WAM4, WAM2-WAM1,
WAM4-WAM3, LAM1, LAM2, LAM3,
LAM4, LAM2-LAM1, LAM4-LAM3
***: 1 to 200 (1 step)
F1 = ********** ### Substitutes a value into variable
F1. For **********, a real number of
10 or fewer digits can be specified
including a sign and the decimal
point.
###: nm, dB, dBm, pW, nW, µW, mW,
W, THz, cm
-1
(AQ6375/AQ6375B),
’ ’ (without units)
**********: –999999999 to 9999999999
(1 step)
F2 = ********** Substitutes a value into ### variable
F2. For **********, a real number of
10 or fewer digits can be specified,
including a sign and the decimal
point.
###: nm, dB, dBm, pW, nW, µW, mW,
W, THz, cm
-1
(AQ6375/AQ6375B),
’ ’ (without units)
**********: –999999999 to 9999999999
(1 step)
F1 = @@@@@ Copies the contents of variable
@@@@@ to the variable F1.
@@@@@: E
1
, G, H, I, J, K, O
1
, P, Q,
R, S, T
1
, U
1
, V
1
, X, Y, Z, WM, W1, W2,
W2-W1, W(CH), LM, L1, L2, L2-L1,
L(CH), SPWD, MEANWL, PKWL,
PKLVL, MODN, GONO, SMSR,
SMSR2, WDMCHN, WDMWL(CH),
WDMLVL(CH), WDMSNR(CH),
NFCHN, NFWL(CH), NFLVLI(CH),
NFLVLO(CH), NFASELV(CH),
NFGAIN(CH), NFNF(CH), MKPWR,
PMD, M, N, CH, WAM1, WAM2,
WAM3, WAM4, WAM2-WAM1,
WAM4-WAM3, LAM1, LAM2, LAM3,
LAM4, LAM2-LAM1, LAM4-LAM3
F2 = @@@@@ Copies the contents of variable
@@@@@ to the variable F2.
@@@@@: E
1
, G, H, I, J, K, O
1
, P, Q,
R, S, T
1
, U
1
, V
1
, X, Y, Z, WM, W1, W2,
W2-W1, W(CH), LM, L1, L2, L2-L1,
L(CH), SPWD, MEANWL, PKWL,
PKLVL, MODN, GONO, SMSR,
SMSR2, WDMCHN, WDMWL(CH),
WDMLVL(CH), WDMSNR(CH),
NFCHN, NFWL(CH), NFLVLI(CH),
NFLVLO(CH), NFASELV(CH),
NFGAIN(CH), NFNF(CH), MKPWR,
PMD, M, N, CH, WAM1, WAM2,
WAM3, WAM4, WAM2-WAM1,
WAM4-WAM3, LAM1, LAM2, LAM3,
LAM4, LAM2-LAM1, LAM4-LAM3
@ = LEVEL
(****.***nm)
Substitutes the level of the point of
wavelength ****.*** nm on an active
trace into variable @.
@: G, H, I, J, K, P, Q, R, S, X, Y, Z
****.***: 600.000 to 1700.000
(0.001 step)
@ = LEVEL
(@@@@@)
Substitutes the level of the point
of the wavelength @@@@@
(variable) on the active trace into
variable @.
@: E
1
, G, H, I, J, K, O
1
, P, Q, R, S, T
1
,
U
1
, V
1
, X, Y, Z
@@@@@: G, H, I, J, K, P, Q, R, S, X,
Y, Z, WM, W1, W2, W(CH), MEANWL,
PKWL, WDMLVL(CH), WDMWL(CH),
NFWL(CH)
