YOKOGAWA AQ6370C User Manual

App-12
IM AQ6370C-17EN
AQ6317 Series Operates in AQ6370C/AQ6370D/AQ6373/AQ6373B/ Remarks
Control AQ6317- AQ6375/AQ6375B Control Command
Command Comp Mode Corresponding to AQ6317 Command
SHI1
▲
:SENSe:SENSe<wsp>HIGH1|3;
Chopper
:SENSe:CHOPer<wsp>OFF|0
Unused
SHI2
▲
:SENSe:SENSe<wsp>HIGH2|4;
Chopper
:SENSe:CHOPer<wsp>OFF|0
Unused
SHI3
▲
:SENSe:SENSe<wsp>HIGH3|5;
Chopper
:SENSe:CHOPer<wsp>OFF|0
Unused
SKM**.*
○
:DISPlay[:WINDow]:TRACe:Y2
[:SCALe]:UNIT<wsp>DB/KM|2
:DISPlay[:WINDow]:TRACe:Y2
[:SCALe]:PDIVision<wsp><NRf>
[DB/KM]
SLIN*.***
○
:DISPlay[:WINDow]:TRACe:Y2
[:SCALe]:UNIT<wsp>LINear|1
:DISPlay[:WINDow]:TRACe:Y2
[:SCALe]:PDIVision<wsp><NRf>
SLOG**.*
○
:DISPlay[:WINDow]:TRACe:Y2
[:SCALe]:UNIT<wsp>DB|0
:DISPlay[:WINDow]:TRACe:Y2
[:SCALe]:PDIVision<wsp><NRf>
[DB]
SMEAS
○
:INITIate:SMODe<wsp>SEGment|4
SMID
○
:SENSe:SENSe<wsp>MID|2
SMIN***.*
○
:DISPlay[:WINDow]:TRACe:Y2
[:SCALe]:SMINimum<wsp><NRf>
SMINP***.*
○
:DISPlay[:WINDow]:TRACe:Y2
[:SCALe]:SMINimum<wsp><NRf>[%]
SMPL****
▲
:SENSe:SWEep:POINts<wsp><integer>
Diff.parameter range
SMSR*
○
:CALCulate:PARameter[:CATegory]
:SMSR:MODE<wsp>SMSR1|SMSR2
SNAT
○
:SENSe:SENSe<wsp>NAUT|1
SNHD
○
:SENSe:SENSe<wsp>NHLD|0
SP=LM
○
:CALCulate:LMARker:SSPan
SPAN****.*
▲
:SENSe:WAVelength:SPAN<wsp><NRf>[M]
Diff. parameter range
SPANF***.***
▲
-
Diff. parameter range
SPLIT
○
:DISPlay[:WINDow]:SPLit<wsp>ON|1
SPN=W
○
-
SPS***.*
○
:DISPlay[:WINDow]:TRACe:Y2[:SCALe]:
UNIT<wsp>%|3
:DISPlay[:WINDow]:TRACe:Y2[:SCALe]:
PDIVision<wsp><NRf>[%]
SRLMK*
○
:CALCulate:LMARker:SRANge<wsp>
OFF|ON|0|1
SRMSK***
○
-
SRQ*
○
*SRE<wsp><integer>
SSE*
×
-
SSMSK**.**
○
:CALCulate:PARameter[:CATegory]:
SMSR:MASK<wsp><NRf>[M]
SSUNT?
○
:DISPlay[:WINDow]:TRACe:Y2
[:SCALe]:UNIT?
List of the AQ6317-Compatible Commands
