AQ6317 Series Operates in AQ6370C/AQ6370D/AQ6373/AQ6373B/ Remarks
Control AQ6317- AQ6375/AQ6375B Control Command
Command Comp Mode Corresponding to AQ6317 Command
TRB?
▲
:TRACe:ATTRibute:TRB?
Diff. talker format
2: MAX HOLD / MIN HOLD
TRC?
×
:TRACe:ATTRibute:TRC?
TRFMT*
○
-
UCWRN*
○
:SYSTem:DISPlay:UNCal<wsp>
OFF|ON|0|1
UHLD*
○
:DISPlay[:WINDow]:SPLit<wsp>ON|1;
:DISPlay[:WINDow]:SPLit:HOLD:
UPPer<wsp>OFF|ON|0|1
ULTRA*
○
:DISPlay[:WINDow]:SPLit<wsp>ON|1;
:DISPlay[:WINDow]:SPLit:POSition<wsp>
TRA,UP|LOW|0|1
ULTRB*
○
:DISPlay[:WINDow]:SPLit<wsp>ON|1;
:DISPlay[:WINDow]:SPLit:POSition<wsp>
TRB,UP|LOW|0|1
ULTRC*
○
:DISPlay[:WINDow]:SPLit<wsp>ON|1;
:DISPlay[:WINDow]:SPLit:POSition<wsp>
TRC,UP|LOW|0|1
WARN?
▲
:SYSTem:ERRor[:NEXT]?
WCAL****.***
▲
:CALibration:WAVelength:EXTernal:
Diff. parameter range
SOURce<wsp>LASer|0;
CALibration:WAVelength:EXTernal:
WAVelength<wsp><NRf>[M]
WCALG****.***
▲
:CALibration:WAVelength:EXTernal:
Diff. parameter range
SOURce<wsp>GASCell|1;
CALibration:WAVelength:EXTernal:
WAVelength<wsp><NRf>[M]
WCALS
○
:CALibration:WAVelength:INTernal
[:IMMediate]
WCALT****;#.###
▲
:CALibration:WAVelength:OFFSet:
Diff. parameter range
TABLe<wsp><integer>,<NRf>[DB]
WDMAN
○
:CALCulate:CATegory<wsp>WDM|10
WDMCHAUT*
×
-
No parameter
WDMCHSW***;#
×
-
WDMDIF**.**
▲
:CALCulate:PARameter[:CATegory]
Set only in WDM Analysis, not in NF
:WDM:MDIFf<wsp><NRf>[DB]
Analysis
WDMDISP*
▲
:CALCulate:PARameter[:CATegory]
Diff. parameter
:WDM:DTYPe<wsp><display type>
0: ABSOLUTE
<display type>=ABSolute|0,
1: RELATIVE
RELatibe|1,MDRift|2,GDRift|3
3: DRIFT(MEAS)
4: DRIFT(GRID)
WDMDSPMSK***
▲
:CALCulate:PARameter[:CATegory]
Diff. parameter range
:WDM:DMASk<wsp><NRf>[DB]
WDMDUAL*
○
:CALCulate:PARameter[:CATegory]
:WDM:DUAL<wsp>OFF|ON|0|1
WDMMAX***
×
-
No parameter
WDMMR
○
:CALCulate:PARameter[:CATegory]
:WDM:MMReset
List of the AQ6317-Compatible Commands
