YOKOGAWA AQ6370C User Manual

App-15
IM AQ6370C-17EN
AQ6317-Compatible GP-IB Commands
1
2
3
4
5
6
7
8
App
Index
AQ6317 Series Operates in AQ6370C/AQ6370D/AQ6373/AQ6373B/ Remarks
Control AQ6317- AQ6375/AQ6375B Control Command
Command Comp Mode Corresponding to AQ6317 Command
WDMNOI*
▲
[NOISE_ALGO is Auto Center]
Diff. set value
(NOISE POI = CTR)
0: AUTO-FIX
:CALCulate:PARameter[:CATegory]
1: AUTO-CTR
:WDM:NALGo<wsp>ACENter|2
Set only in WDM Analysis, not in NF
[NOISE_ALGO is MANUAL Fix]
Analysis
(NOISE POI = CTR)
:CALCulate:PARameter[:CATegory]
:WDM:NALGo<wsp>MFIX|1;
:CALCulate:PARameter[:CATegory]
:WDM:FALGo<wsp>LINear|0;
WDMNOIBW****
○
:CALCulate:PARameter[:CATegory]:
WDM:NBW<wsp><NRf>[M|HZ]
WDMNOIP**.**
▲
:CALCulate:PARameter[:CATegory]:
Valid only when NOISE ALGO is set to
WDM:FALGo<wsp>LINear|0;
MANUAL FIX
:CALCulate:PARameter[:CATegory]:
WDM:NBW<wsp><NRf>[M]
WDMOS*
○
:CALCulate:PARameter[:CATegory]:
WDM:RELation<wsp>OFFSet|SPACing|0|1
WDMREF*
×
-
WDMREFDAT*
×
-
WDMRH
○
:CALCulate:PARameter[:CATegory]
:WDM:RCH<wsp>0
WDMRN***
○
:CALCulate:PARameter[:CATegory]
:WDM:RCH<wsp><integer>
WDMSLOPE*
○
:CALCulate:PARameter[:CATegory]
:WDM:OSLope<wsp>OFF|ON|0|1
WDMTCOPY
○
:HCOPY[:IMMediate]:FUNCtion
:CALCulate:LIST
WDMTH**.*
▲
:CALCulate:PARameter[:CATegory]
Set only in WDM Analysis, not in NF
:WDM:TH<wsp><NRf>[DB]
Analysis
WDMUNT*
×
:CALCulate:MARKer:UNIT<wsp>
WAVelength|FREQuency|0|1
WLSFT**.***
○
:SENSe:CORRection:WAVelength:
SHIFt<wsp><NRf>[M]
WMKR****.***
▲
:CALCulate:MARKer:X<wsp>0,<NRf>[M]
Diff. parameter range
WNFAN
○
:CALCulate:CATegory<wsp>NF|11
WNFCVF*
▲
:CALCulate:PARameter[:CATegory]:
Valid only when ASE ALGO is set to
NF:FALGo<wsp><algorhythm>
MANUAL FIX or MANUAL CTR
<algorhythm>=AFIX|0,MFIX|1,
ACENter|2,MCENter|3
WNFFA**.**
▲
:CALCulate:PARameter[:CATegory]:
Valid only when ASE ALGO is set to
NF:FARea<wsp><NRf>[M|HZ]
MANUAL FIX
WNFNP**.**
▲
:CALCulate:PARameter[:CATegory]:
Valid only when all the following conditions
NF:MARea<wsp><NRf>[M|HZ]
are satisfied
1. ASE ALGO is set to MANUAL FIX or
MANUAL CTR
2. FITTING ALGO is set besides LINEAR
WNFOFI***.**
○
:CALCulate:PARameter[:CATegory]:
NF:IOFFset<wsp><NRf>[DB]
WNFOFO***.**
○
:CALCulate:PARameter[:CATegory]:
NF:OOFFset<wsp><NRf>[DB]
WNFSSE*
×
-
No parameter
List of the AQ6317-Compatible Commands
