Function Control Command
CALCulate G@@@@
LOG MATH@@@@
G = C-F(LOG)
:CALCulate:MATH:TRG<wsp>C-F(LOG)
G = F-C(LOG)
:CALCulate:MATH:TRG<wsp>F-C(LOG)
G = C+F(LOG)
:CALCulate:MATH:TRG<wsp>C+F(LOG)
G = E-F(LOG)
:CALCulate:MATH:TRG<wsp>E-F(LOG)
G = F-E(LOG)
:CALCulate:MATH:TRG<wsp>F-E(LOG)
G = E+F(LOG)
:CALCulate:MATH:TRG<wsp>E+F(LOG)
LIN MATH@@@@
G = C+F(LIN)
:CALCulate:MATH:TRG<wsp>C+F(LIN)
G = C-F(LIN)
:CALCulate:MATH:TRG<wsp>C-F(LIN)
G = F-C(LIN)
:CALCulate:MATH:TRG<wsp>F-C(LIN)
G = E+F(LIN)
:CALCulate:MATH:TRG<wsp>E+F(LIN)
G = E-F(LIN)
:CALCulate:MATH:TRG<wsp>E-F(LIN)
G = F-E(LIN)
:CALCulate:MATH:TRG<wsp>F-E(LIN)
NORMALIZE@@@@
G = NORM A
:CALCulate:MATH:TRG<wsp>NORMA
G = NORM B
:CALCulate:MATH:TRG<wsp>NORMB
G = NORM C
:CALCulate:MATH:TRG<wsp>NORMC
CURVE FIT@@@@
G = CVFIT A
:CALCulate:MATH:TRG<wsp>CVFTA
G = CVFIT B
:CALCulate:MATH:TRG<wsp>CVFTB
G = CVFIT C
:CALCulate:MATH:TRG<wsp>CVFTC
G = MKR FIT
:CALCulate:MATH:TRG<wsp>MKRFT
THRESH **dB
:CALCulate:MATH:TRG:CVFT:THResh<wsp><NRf>[DB]
OPERATION AREA
:CALCulate:MATH:TRG:CVFT:OPARea<wsp>ALL|INL1-L2|
OUTL1-L2|0|1|2
FITTING ALGO
:CALCulate:MATH:TRG:CVFT:FALGo<wsp>GAUSS|LORENz|
3RD|4TH|5TH|0|1|2|3|4
CURVE FIT PK@@@@
G = PKCVFIT A
:CALCulate:MATH:TRG<wsp>PKCVFTA
G = PKCVFIT B
:CALCulate:MATH:TRG<wsp>PKCVFTB
G = PKCVFIT C
:CALCulate:MATH:TRG<wsp>PKCVFTC
THRESH **dB
:CALCulate:MATH:TRG:PCVFt:THResh<wsp><NRf>[DB]
OPERATION AREA
:CALCulate:MATH:TRG:CVFT:OPARea<wsp>ALL|INL1-L2|
OUTL1-L2|0|1|2
FITTING ALGO
:CALCulate:MATH:TRG:CVFT:FALGo<wsp>GAUSS
|LORENz|3RD|4TH|5TH|0|1|2|3|4
TRACE LIST
-
TRACE COPY
:TRACe:COPY<wsp><source:TRACe name>,
<destination:TRACe name>
TRACE CLEAR
:TRACe:DELete<wsp><:TRACe name>
7.2 Table of Correspondence between Soft Keys and Remote Commands
