YOKOGAWA AQ6370C User Manual

7-8
IM AQ6370C-17EN
TRACE
Function Control Command Remarks
ACTIVE TRACE
A
:TRACe:ACTive<wsp>TRA
B
:TRACe:ACTive<wsp>TRB
C
:TRACe:ACTive<wsp>TRC
D
:TRACe:ACTive<wsp>TRD
E
:TRACe:ACTive<wsp>TRE
F
:TRACe:ACTive<wsp>TRF
G
:TRACe:ACTive<wsp>TRG
VIEW @ DISP/BLANK
:TRACe:STATe:<:TRACe name><wsp>ON|OFF|1|0
WRITE @
:TRACe:ATTRibute:<:TRACe name><wsp>WRITe|0
FIX @
:TRACe:ATTRibute:<tarce name><wsp>FIX|1
HOLD @
MAX HOLD
:TRACe:ATTRibute:<:TRACe name><wsp>MAX|2
MIN HOLD
:TRACe:ATTRibute:<:TRACe name><wsp>MIN|3
ROLL AVG @ ***
:TRACe:ATTRibute:RAVG:<:TRACe name><wsp>
<integer>
CALCULATE C@@@@
LOG MATH@@@@
C = A-B(LOG)
:CALCulate:MATH:TRC<wsp>A-B(LOG)
C = B-A(LOG)
:CALCulate:MATH:TRC<wsp>B-A(LOG)
C = A+B(LOG)
:CALCulate:MATH:TRC<wsp>A+B(LOG)
LIN MATH@@@@
C = A+B(LIN)
:CALCulate:MATH:TRC<wsp>A+B(LIN)
C = A-B(LIN)
:CALCulate:MATH:TRC<wsp>A-B(LIN)
C = B-A(LIN)
:CALCulate:MATH:TRC<wsp>B-A(LIN)
C = 1-k(A/B) k: *.****
:CALCulate:MATH:TRC:K<wsp><NRf>;
:CALCulate:MATH:TRC<wsp>1-K(A/B)
C = 1-k(B/A) k: *.****
:CALCulate:MATH:TRC:K<wsp><NRf>;
:CALCulate:MATH:TRC<wsp>1-K(B/A)
CALCULATE F@@@@
LOG MATH@@@@
F = C-D(LOG)
:CALCulate:MATH:TRF<wsp>C-D(LOG)
F = D-C(LOG)
:CALCulate:MATH:TRF<wsp>D-C(LOG)
F = C+D(LOG)
:CALCulate:MATH:TRF<wsp>C+D(LOG)
F = D-E(LOG)
:CALCulate:MATH:TRF<wsp>D-E(LOG)
F = E-D(LOG)
:CALCulate:MATH:TRF<wsp>E-D(LOG)
F = D+E(LOG)
:CALCulate:MATH:TRF<wsp>D+E(LOG)
CALCulate F@@@@
LIN MATH@@@@
F = C+D(LIN)
:CALCulate:MATH:TRF<wsp>C+D(LIN)
F = C-D(LIN)
:CALCulate:MATH:TRF<wsp>C-D(LIN)
F = D-C(LIN)
:CALCulate:MATH:TRF<wsp>D-C(LIN)
F = D+E(LIN)
:CALCulate:MATH:TRF<wsp>D+E(LIN)
F = D-E(LIN)
:CALCulate:MATH:TRF<wsp>D-E(LIN)
F = E-D(LIN)
:CALCulate:MATH:TRF<wsp>E-D(LIN)
POWER/NBW@@@@@@@@@@@
F=PWR/NBW A
:CALCulate:MATH:TRF<wsp>PWRNBWA
AQ6370C/AQ6370D/
AQ6375B
F=PWR/NBW B
:CALCulate:MATH:TRF<wsp>PWRNBWB
AQ6370C/AQ6370D/
AQ6375B
F=PWR/NBW C
:CALCulate:MATH:TRF<wsp>PWRNBWC
AQ6370C/AQ6370D/
AQ6375B
F=PWR/NBW D
:CALCulate:MATH:TRF<wsp>PWRNBWD
AQ6370C/AQ6370D/
AQ6375B
F=PWR/NBW E
:CALCulate:MATH:TRF<wsp>PWRNBWE
AQ6370C/AQ6370D/
AQ6375B
BANDWIDTH
:CALCulate:MATH:TRF:PNBW:BWIDth|
BAND
AQ6370C/AQ6370D/
AQ6375B
7.2 Table of Correspondence between Soft Keys and Remote Commands
