YOKOGAWA AQ6370C User Manual

7-7
IM AQ6370C-17EN
Remote Commands
1
2
3
4
5
6
7
8
App
Index
ZOOM
Function Control Command Remarks
ZOOM CENTER WL
****.***nm
:DISPlay[:WINDow]:TRACe:X[:SCALe]:CENTer<
wsp><NRf>[M]
ZOOM CENTER FREQ
***.****THz
:DISPlay[:WINDow]:TRACe:X[:SCALe]:CENTer<
wsp><NRf>[HZ]
ZOOM CENTER WNUM
****.***cm-1
:DISPlay[:WINDow]:TRACe:X[:SCALe]:CENTer<
wsp><NRf>
AQ6375/
AQ6375B
ZOOM SPAN ****.*nm
:DISPlay[:WINDow]:TRACe:X[:SCALe]:SPAN<ws
p><NRf>[M]
ZOOM SPAN ***.**THz
:DISPlay[:WINDow]:TRACe:X[:SCALe]:SPAN<ws
p><NRf>[HZ]
ZOOM SPAN WNUM
****.*cm-1
:DISPlay[:WINDow]:TRACe:X[:SCALe]:
SPAN <wsp><NRf>
AQ6375/
AQ6375B
ZOOM START WL
****.***nm
:DISPlay[:WINDow]:TRACe:X[:SCALe]:STARt<w
sp><NRf>[M]
ZOOM START FREQ
:DISPlay[:WINDow]:TRACe:X[:SCALe]:
***.****THz
STARt<wsp><NRf>[HZ]
ZOOM START WNUM
****.***cm-1
:DISPlay[:WINDow]:TRACe:X[:SCALe]:
STARt <wsp><NRf>
AQ6375/
AQ6375B
ZOOM STOP WL ****.***nm
:DISPlay[:WINDow]:TRACe:X[:SCALe]:STOP<ws
p><NRf>[M]
ZOOM STOP FREQ
***.****THz
:DISPlay[:WINDow]:TRACe:X[:SCALe]:STOP<ws
p><NRf>[HZ]
ZOOM STOP WNUM
****.***cm-1
:DISPlay[:WINDow]:TRACe:X[:SCALe]:
STOP <wsp><NRf>
AQ6375/
AQ6375B
PEAK→ZOOMCTR
:CALCulate:MARKer:MAXimum:SZCEnter
OVERVIEW DISPLAY OFF/
L/R
:DISPlay[:WINDow]:OVIew:POSition<wsp>
OFF|LEFT|RIGHt|0|1|2
OVERVIEW SIZE
:DISPlay[:WINDow]:OVIew:SIZE<wsp>
LARGE/SMALL
LARGe|SMALl|0|1
INITIAL
:DISPlay[:WINDow]:TRACe:X[:SCALe]:INITial
ize
DISPLAY
Function Control Command Remarks
NORMAL DISPLAY
:DISPlay[:WINDow]:SPLit<wsp>OFF|0
SPLIT DISPLAY
:DISPlay[:WINDow]:SPLit<wsp>ON|1
SPLIT DISPLAY
TRACE A UP/LOW
:DISPlay[:WINDow]:SPLit:POSition<wsp>TRA,UP|LOW|0|1
TRACE B UP/LOW
:DISPlay[:WINDow]:SPLit:POSition<wsp>TRB,UP|LOW|0|1
TRACE C UP/LOW
:DISPlay[:WINDow]:SPLit:POSition<wsp>TRC,UP|LOW|0|1
TRACE D UP/LOW
:DISPlay[:WINDow]:SPLit:POSition<wsp>TRD,UP|LOW|0|1
TRACE E UP/LOW
:DISPlay[:WINDow]:SPLit:POSition<wsp>TRE,UP|LOW|0|1
TRACE F UP/LOW
:DISPlay[:WINDow]:SPLit:POSition<wsp>TRF,UP|LOW|0|1
TRACE G UP/LOW
:DISPlay[:WINDow]:SPLit:POSition<wsp>TRG,UP|LOW|0|1
HOLD
UPPER HOLD ON/
OFF
:DISPlay[:WINDow]:SPLit:HOLD:UPPer<wsp>
OFF|ON|0|1
LOWER HOLD ON/
OFF
:DISPlay[:WINDow]:SPLit:HOLD:LOWer<wsp>
OFF|ON|0|1
LABEL
:DISPlay[:WINDow]:TEXT:DATA<wsp><string>
NOISE MASK ***dB
:DISPlay[:WINDow]:TRACe:Y:NMASk<wsp><NRf>
[DB]
MASK LINE VERT/HRZN
:DISPlay[:WINDow]:TRACe:Y:NMASk:TYPE<wsp>
VERTical| HORIzontal|0|1
TRACE CLEAR
ALL TRACE
:DISPlay[:WINDow]:TEXT:CLEar
DISPLAY OFF
:DISPlay[:WINDow]<wsp>OFF|ON|0|1
AQ6370C/
AQ6370D/
AQ6373B/
AQ6375B
7.2 Table of Correspondence between Soft Keys and Remote Commands
