YOKOGAWA AQ6370C User Manual

7-6
IM AQ6370C-17EN
SETUP
Function Control Command Remarks
RESOLUTION *.***nm
:SENSe:BANDwidth|:BWIDth[:RESolution]
<wsp><NRf>[M|Hz]
SENS/MODE @@@@@@
NORM/HOLD
:SENSe:SENSe<wsp>NHLD|0
NORM/AUTO
:SENSe:SENSe<wsp>NAUT|1
NORM
:SENSe:SENSe<wsp>NORMal|6
MID
:SENSe:SENSe<wsp>MID|2
HIGH1
:SENSe:SENSe<wsp>HIGH1|3
AQ6370C/AQ6370D/
AQ6373/AQ6373B
HIGH1/CHOP
:SENSe:SENSe<wsp>HIGH1|3
AQ6375/AQ6375B
HIGH2
:SENSe:SENSe<wsp>HIGH2|4
AQ6370C/AQ6370D/
AQ6373/AQ6373B
HIGH2/CHOP
:SENSe:SENSe<wsp>HIGH2|4
AQ6375/AQ6375B
HIGH3
:SENSe:SENSe<wsp>HIGH3|5
AQ6370C/AQ6370D/
AQ6373/AQ6373B
HIGH3/CHOP
:SENSe:SENSe<wsp>HIGH3|5
AQ6375/AQ6375B
CHOP MODE @@@@@
OFF
:SENSe:CHOPPer<wsp>OFF|0
AQ6370C/AQ6370D/
AQ6373/AQ6373B
SWITCH
:SENSe:CHOPPer<wsp>SWITch|2
AQ6370C/AQ6370D/
AQ6373/AQ6373B
AVG TIMES ***
:SENSe:AVERage:COUNt<wsp><integer>
SAMPLING POINT
AUTO
:SENSe:SWEep:POINts:AUTO<wsp>OFF|
ON|0|1
SAMPLING POINT *****
:SENSe:SWEep:POINts<wsp><integer>
SAMPLING INTVL
*.****nm
:SENSe:SWEep:STEP<wsp><NRf> [M]
MEAS WL AIR/VAC
:SENSe:CORRection:RVELocity:MEDium
<wsp>AIR|VACuum|0|1
SWEEP SPEED 1x/2x
:SENSe:SWEep:SPEed<wsp>1x|2x|0|1
AQ6370C/AQ6370D/
AQ6373B/AQ6375B
HORZN SCALE nm/THz
:UNIT:X<wsp>WAVelength|FREQuency|0|1
AQ6370C/AQ6370D/
AQ6373/AQ6373B
HORZN SCALE @@@@
nm
:UNIT:X<wsp>WAVelength|0
THz
:UNIT:X<wsp>FREQuency|1
cm-1
:UNIT:X<wsp>WNUMber|2
AQ6375/AQ6375B
PLS LIGHT MEASURE
PEAK HOLD
**msec
:TRIGger[:SEQuence]:STATe<wsp>
OFF|ON|PHOLd|0|1|2
EXT TRIGGER
MODE
:TRIGger[:SEQuence]:STATe<wsp>
OFF|ON|PHOLd|0|1|2
GATE MODE
***.*msec
:TRIGger[:SEQuence]:GATE:TIMe
AQ6370C/AQ6370D/
AQ6373B/AQ6375B
GATE LOGIC
:TRIGger[:SEQuence]:GATE:LOGic
AQ6370C/AQ6370D/
AQ6373B/AQ6375B
TRIGGER SETTING
EDGE RISE/FALL
:TRIGger[:SEQuence]:SLOPe<wsp>RISE|
FALL|0|1
DELAY****.*μs
:TRIGger[:SEQuence]:DELay<wsp><NRf>
[S]
TLS SYNC SWEEP
ON/OFF
:SENSe:SWEep:TLSSync<wsp>OFF|ON|0|1
AQ6370C/AQ6375
RESOLN CORRECT
:SENSe:SETting:CORRection<wsp>
OFF|ON|0|1
AQ6370C/AQ6370D/
AQ6373/AQ6373B
SMOOTHING ON/OFF
:SENSe:SETTing:SMOothing<wsp>
OFF|ON|0|1
AQ6373/AQ6373B/
AQ6375B
FIBER CORE SIZE
:SENSe:SETTing:FIBer<wsp>SMALl|LAR
Ge|0|1
AQ6373/AQ6373B
FIBER CONNECTOR
:SENSe:SETting:FCONnector<wsp>
NORMal|ANGLed|0|1
AQ6370C/AQ6370D
7.2 Table of Correspondence between Soft Keys and Remote Commands
