YOKOGAWA AQ6370C User Manual

7-5
IM AQ6370C-17EN
Remote Commands
1
2
3
4
5
6
7
8
App
Index
LEVEL
Function Control Command
REF LEVEL
LOG
:DISPlay:[:WINDow]:Y1[:SCAle]:RLEVel<wsp><NRf>[D
BM]
LINEAR
:DISPlay[:WINDow]:Y1[:SCALe]:RLEVel<wsp><NRf>
[NW|UM|MW]
LOG SCALE**.*dB/D
:DISPlay[:WINDow]:TRACe:Y1[:SCALe]:PDIVision<wsp>
<NRf> [DB]
LIN SCALE
:DISPlay[:WINDow]:TRACe:Y1[:SCALe]:SPACing<wsp>
LINear|1
LIN BASE LEVEL**.*mW
:DISPlay[:WINDow]:Y1[:SCALe]:BLEVel<wsp><NRf>[MW]
PEAK→REFLEVEL
:CALCulate:MARKer:MAXimum:SRLevel
Function Control Command
AUTO REF LEVEL ON/OFF
:CALCulate:MARKer:MAXimum:SRLevel:AUTO
LEVEL UNIT dBm / dBm/nm
:DISPlay[:WINDow]:TRACe:Y1[:SCALe]:UNIT<wsp>
DBM|DBM/NM
Y SCALE SETTING
Y SCALE DIVISION
8/10/12
:DISPlay[:WINDow]:TRACe:Y[:SCALe]:DNUMber<wsp>
8| 10|12
REF LEVEL POSITION
**DIV
:DISPlay[:WINDow]:TRACe:Y1[:SCALe]:RPOSition<wsp>
<integer>[DIV]
SUB LOG**.*dB/D
:DISPlay[:WINDow]:TRACe:Y2[:SCALe]:PDIVision<wsp>
<NRf>[DB]
SUB LIN*.***/D
:DISPlay[:WINDow]:TRACe:Y2[:SCALe]:PDIVision<wsp>
<NRf>
SUB SCALE**.*dB/km
:DISPlay[:WINDow]:TRACe:Y2[:SCALe]:PDIVision<wsp>
<NRf>[DB/KM]
SUB SCALE**.*%/D
:DISPlay[:WINDow]:TRACe:Y2[:SCALe]:PDIVision<wsp>
<NRf>[%]
OFST LVL or
:DISPlay[:WINDow]:TRACe:Y2[:SCALe]:OLEVel<wsp>
SCALE MIN **.*dB
<NRf>[DB]
LENGTH**.***km
:DISPlay[:WINDow]:TRACe:Y2[:SCALe]:LENGth<wsp>
<NRf>[KM]
AUTO SUB SCALE ON/OFF
:DISPlay[:WINDow]:TRACe:Y2[:SCALe]:AUTO<wsp>OFF|
ON|0|1
SUB REF LVL POSITION
**DIV
:DISPlay[:WINDow]:TRACe:Y2[:SCALe]:RPOSition<wsp>
<integer>[DIV]
Note
For the AQ6375, dBm/nm and W/nm cannot be selected for LEVEL UNIT when the horizontal
axis is wavenumber. (DBM/NM parameters cannot be set. )
7.2 Table of Correspondence between Soft Keys and Remote Commands
