YOKOGAWA AQ6370C User Manual

7-21
IM AQ6370C-17EN
Remote Commands
1
2
3
4
5
6
7
8
App
Index
ANALYSIS Parameters Control Command Remarks
THRESH2
**.**dB
:CALCulate:PARameter[:CATegory]:DFBLd
<wsp>SWIDth,TH2,<NRf>[DB]
K
:CALCulate:PARameter[:CATegory]:DFBLd
<wsp>SWIDth,K,<NRf>
MODE FIT ON/
OFF
:CALCulate:PARameter[:CATegory]:DFBLd
<wsp>SWIDth,MFIT,OFF|ON|0|1
MODE DIFF
*.**dB
:CALCulate:PARameter[:CATegory]:DFBLd
<wsp>SWIDth,MDIFf,<NRf>[DB]
SMSR
SMSR MODE
:CALCulate:PARameter[:CATegory]:DFBLd
<wsp>SMSR,SMODe,SMSR1|SMSR2|SMSR3|SMSR4
“SMSR3” and
“SMSR4” can be used
on the AQ6370C/
AQ6370D/AQ6373B/
AQ6375B.
SMSR MASK
±*.**nm
:CALCulate:PARameter[:CATegory]:DFBLd
<wsp>SMSR,SMASk,<NRf>[M]
MODE DIFF
*.**dB
:CALCulate:PARameter[:CATegory]:DFBLd
<wsp>SMSR,MDIFf,<NRf>[DB]
RMS
AQ6370C/AQ6370D/
AQ6373B/AQ6375B
ALGO
:CALCulate:PARameter[:CATegory]:DFBLd
<wsp>RMS,ALGO,<data>
AQ6370C/AQ6370D/
AQ6373B/AQ6375B
THRESH **.**dB
:CALCulate:PARameter[:CATegory]:DFBLd
<wsp>RMS,TH,<NRf>[DB]
AQ6370C/AQ6370D/
AQ6373B/AQ6375B
K
:CALCulate:PARameter[:CATegory]:DFBLd
<wsp>RMS,K,<NRf>
AQ6370C/AQ6370D/
AQ6373B/AQ6375B
MODE DIFF
*.**dB
:CALCulate:PARameter[:CATegory]:DFBLd
<wsp>RMS,MDIFf,<NRf>[DB]
AQ6370C/AQ6370D/
AQ6373B/AQ6375B
POWER AQ6370C/AQ6370D/
AQ6373B/AQ6375B
SPAN **.**nm
:CALCulate:PARameter[:CATegory]:DFBLd
<wsp>POWer,SPAN,<NRf>[M]
AQ6370C/AQ6370D/
AQ6373B/AQ6375B
OSNR AQ6370C/AQ6370D/
AQ6373B/AQ6375B
MODE DIFF
*.**dB
:CALCulate:PARameter[:CATegory]:DFBLd
<wsp>OSNR,MDIFf,<NRf>[DB]
AQ6370C/AQ6370D/
AQ6373B/AQ6375B
NOISE ALGO
:CALCulate:PARameter[:CATegory]:DFBLd
<wsp>OSNR,NALGo,<data>
AQ6370C/AQ6370D/
AQ6373B/AQ6375B
NOISE AREA
**.**nm
:CALCulate:PARameter[:CATegory]:DFBLd
<wsp>OSNR,NARea,<NRf>[M]
AQ6370C/AQ6370D/
AQ6373B/AQ6375B
MASK AREA
*.**nm
:CALCulate:PARameter[:CATegory]:DFBLd
<wsp>OSNR,MARea,<NRf>[M]
AQ6370C/AQ6370D/
AQ6373B/AQ6375B
FITTING ALGO
:CALCulate:PARameter[:CATegory]:DFBLd
<wsp>OSNR,FALGo,<data>
AQ6370C/AQ6370D/
AQ6373B/AQ6375B
NOISE BW
**.**nm
:CALCulate:PARameter[:CATegory]:DFBLd
<wsp>OSNR,NBW,<NRf>[M]
AQ6370C/AQ6370D/
AQ6373B/AQ6375B
SIGNAL
POWER
:CALCulate:PARameter[:CATegory]:DFBLd
<wsp>OSNR,SPOWer,<data>
AQ6370C/AQ6370D/
AQ6373B/AQ6375B
INTEGRAL
RANGE
:CALCulate:PARameter[:CATegory]:DFBLd
<wsp>OSNR,IRANge,<NRf>
AQ6370C/AQ6370D/
AQ6373B/AQ6375B
FP-LD
SPECTRUM WIDTH
ALGO
:CALCulate:PARameter[:CATegory]:FPLD
<wsp>SWIDth,ALGO,<data>
THRESH **.**dB
:CALCulate:PARameter[:CATegory]:FPLD
<wsp>SWIDth,TH,<NRf>[DB]
THRESH2
**.**dB
:CALCulate:PARameter[:CATegory]:FPLD
<wsp>SWIDth,TH2,<NRf>[DB]
K
:CALCulate:PARameter[:CATegory]:FPLD
<wsp>SWIDth,K,<NRf>
MODE FIT ON/
OFF
:CALCulate:PARameter[:CATegory]:FPLD
<wsp>SWIDth,MFIT,OFF|ON|0|1
MODE DIFF
*.**dB
:CALCulate:PARameter[:CATegory]:FPLD
<wsp>SWIDth,MDIFf,<NRf>[DB]
7.3 ANALYSIS Setting Parameters
