YOKOGAWA AQ6370C User Manual

7-22
IM AQ6370C-17EN
ANALYSIS Parameters Control Command Remarks
MEAN WAVELENGTH
ALGO
:CALCulate:PARameter[:CATegory]:FP
LD<wsp>MWAVelength,ALGO,<data>
THRESH **.**dB
:CALCulate:PARameter[:CATegory]:FP
LD<wsp>MWAVelength,TH,<NRf>[DB]
THRESH2 **.**dB
:CALCulate:PARameter[:CATegory]:FP
LD<wsp>MWAVelength,TH2,<NRf>[DB]
K
:CALCulate:PARameter[:CATegory]:FP
LD<wsp>MWAVelength,K,<NRf>
MODE FIT ON/
OFF
:CALCulate:PARameter[:CATegory]:FPLD
<wsp>MWAVelength,MFIT,OFF|ON|0|1
MODE DIFF *.**dB
:CALCulate:PARameter[:CATegory]:FPLD
<wsp>MWAVelength,MDIFf,<NRf>[DB]
TOTAL POWER
OFFSET LEVEL
*.**dB
:CALCulate:PARameter[:CATegory]:FPLD
<wsp>TPOWer,OFFSet,<NRf>[DB]
MODE NO.
ALGO
:CALCulate:PARameter[:CATegory]:FP
LD<wsp>MNUMber,ALGO,<data>
THRESH **.**dB
:CALCulate:PARameter[:CATegory]:FP
LD<wsp>MNUMber,TH,<NRf>[DB]
THRESH2 **.**dB
:CALCulate:PARameter[:CATegory]:FP
LD<wsp>MNUMber,TH2,<NRf>[DB]
K
:CALCulate:PARameter[:CATegory]:FP
LD<wsp>MNUMber,K,<NRf>
MODE FIT ON/
OFF
:CALCulate:PARameter[:CATegory]:FP
LD<wsp>MNUMber,MFIT,OFF|ON|0|1
MODE DIFF
*.**dB
:CALCulate:PARameter[:CATegory]:FP
LD<wsp>MNUMber,MDIFf,<NRf>[DB]
LED
SPECTRUM WIDTH
ALGO
:CALCulate:PARameter[:CATegory]:LE
D<wsp>SWIDth,ALGO,<data>
THRESH **.**dB
:CALCulate:PARameter[:CATegory]:LE
D<wsp>SWIDth,TH,<NRf>[DB]
THRESH2 **.**dB
:CALCulate:PARameter[:CATegory]:LE
D<wsp>SWIDth,TH2,<NRf>[DB]
K
:CALCulate:PARameter[:CATegory]:LE
D<wsp>SWIDth,K,<NRf>
MODE FIT ON/
OFF
:CALCulate:PARameter[:CATegory]:LE
D<wsp>SWIDth,MFIT,OFF|ON|0|1
MODE DIFF
*.**dB
:CALCulate:PARameter[:CATegory]:LE
D<wsp>SWIDth,MDIFf,<NRf>[DB]
MEAN WAVELENGTH
ALGO
THRESH **.**dB
:CALCulate:PARameter[:CATegory]:LE
D<wsp>MWAVelength,TH,<NRf>[DB]
THRESH2 **.**dB
:CALCulate:PARameter[:CATegory]:LE
D<wsp>MWAVelength,TH2,<NRf>[DB]
K
MODE FIT ON/
OFF
:CALCulate:PARameter[:CATegory]:LED
<wsp>MWAVelength,MFIT,OFF|ON|0|1
MODE DIFF
*.**dB
:CALCulate:PARameter[:CATegory]:LED
<wsp>MWAVelength,MDIFf,<NRf>[DB]
TOTAL POWER
OFFSET LEVEL
*.**dB
:CALCulate:PARameter[:CATegory]:LED
<wsp>TPOWer,OFFSet,<NRf>[DB]
SMSR
SMSR MODE
:CALCulate:PARameter[:CATegory]:SMSR:M
ODE<wsp>SMSR1|SMSR2|SMSR3|SMSR4
“SMSR3” and
“SMSR4” can be used
on theAQ6370C/
AQ6373B/AQ6375B.
SMSR MASK ±*.**dB
:CALCulate:PARameter[:CATegory]:SM
SR:MASK<wsp><NRf>[M]POWER
POWER
OFFSET LEVEL
*.**dB
:CALCulate:PARameter[:CATegory]:PO
Wer:OFFSet<wsp><NRf>[DB]
PMD
THRESH LEVEL
*.**dB
:CALCulate:PARameter[:CATegory]:PM
D:TH<wsp><NRf>[DB]
7.3 ANALYSIS Setting Parameters
