ANALYSIS 2 (disabled when in Wavenumber mode)
For the AQ6375/AQ6375B, these parameters cannot be set when in Wavenumber mode.
ANALYSIS Parameters Control Command
WDM (On the AQ6373/AQ6373B, the soft key appears as OSNR(WDM)).
CHANNEL DETECTION SETTING
THRESH LEVEL
:CALCulate:PARameter[:CATegory]:WDM:TH<wsp><NRf>[
DB]
MODE DIFF
**.**dB
:CALCulate:PARameter[:CATegory]:WDM:MDIFf<wsp><NRf
>[DB]
DISPLAY MASK
OFF/ON *.**dB
:CALCulate:PARameter[:CATegory]:WDMASk<wsp><NRf>[
DB]
INTERPOLATATION SETTING
NOISE ALGO
AUTO-FIX
:CALCulate:PARameter[:CATegory]:WDM:NALGo<wsp>AFIX|0
MANUAL-FIX
:CALCulate:PARameter[:CATegory]:WDM:NALGo<wsp>MFIX|1
AUTO-CTR
:CALCulate:PARameter[:CATegory]:WDM:NALGo<wsp>ACENt
er|2
MANUAL-CTR
:CALCulate:PARameter[:CATegory]:WDM:NALGo<wsp>MCENt
er|3
PIT
:CALCulate:PARameter[:CATegory]:WDM:NALGo<wsp>PIT|4
FITTING AREA
:CALCulate:PARameter[:CATegory]:WDM:NARea<wsp><NRf>[M]
MASK AREA
:CALCulate:PARameter[:CATegory]:WDM:MARea<wsp><NRf>[M]
FITTING ALGO
LINEAR
:CALCulate:PARameter[:CATegory]:WDM:FALGo<wsp>LINe
ar|0
GAUSS
:CALCulate:PARameter[:CATegory]:WDM:FALGo<wsp>GAU
Ss|1
LORENZ
:CALCulate:PARameter[:CATegory]:WDM:FALGo<wsp>LORe
nz|2
3RD POLY
:CALCulate:PARameter[:CATegory]:WDM:FALGo<wsp>3RD|3
4TH POLY
:CALCulate:PARameter[:CATegory]:WDM:FALGo<wsp>4TH|4
5TH POLY
:CALCulate:PARameter[:CATegory]:WDM:FALGo<wsp>5TH|5
NOISE BW *.**nm
:CALCulate:PARameter[:CATegory]:WDM:NBW<wsp><NRf>
[M]
DUAL TRACE ON/
OFF
:CALCulate:PARameter[:CATegory]:WDM:DUAL<wsp>OFF|
ON|0|1
DISPLAY SETTING
DISPLAY TYPE
ABSOLUTE
:CALCulate:PARameter[:CATegory]:WDM:DTYPe<wsp>ABSo
lute|0
RELATIVE
:CALCulate:PARameter[:CATegory]:WDM:DTYPe<wsp>RELa
tibe|1 (On the AQ6373/AQ6373B, it cannot be set.)
DRIFT(MEAS)
:CALCulate:PARameter[:CATegory]:WDM:DTYPe<wsp>MDRi
ft|2
DRIFT(GRID)
:CALCulate:PARameter[:CATegory]:WDM:DTYPe<wsp>
GDRift|3 (On the AQ6373/AQ6373B, it cannot be
set.)
CH RELATION
OFFSET
:CALCulate:PARameter[:CATegory]:WDM:RELation<wsp>O
FFSet|0
SPACING
:CALCulate:PARameter[:CATegory]:WDM:RELation<wsp>S
PACing|1
REF CH
:CALCulate:PARameter[:CATegory]:WDM:RCH<wsp><integ
er>
MAX/MIN RESET
:CALCulate:PARameter[:CATegory]:WDM:MMReset
OUTPUT SLOPE
ON/OFF
:CALCulate:PARameter[:CATegory]:WDM:OSLope<wsp>OFF
|ON|0|1
POINT DISPLAY
ON/OFF
:CALCulate:PARameter[:CATegory]:WDM:PDISplay<wsp>O
FF|ON|0|1
7.3 ANALYSIS Setting Parameters
