YOKOGAWA AQ6370C

7-24
IM AQ6370C-17EN
ANALYSIS Parameters Control Command
OTHER SETTING (invalid if other than the AQ6370C/AQ6370D/AQ6373B/AQ6375B.)
SIGNAL POWER
:CALCulate:PARameter[:CATegory]:WDM:SPOWer<wsp>
PEAK|INTegral|0|1
INTEGRAL RANGE
:CALCulate:PARameter[:CATegory]:WDM:IRANge<wsp>
<NRf>
EDFA NF (It is not available on the AQ6373/AQ6373B.)
CHANNNEL DETECTION
THRESH LEVEL
**.**dB
:CALCulate:PARameter[:CATegory]:NF:TH<wsp><NRf>
[DB]
MODE DIFF **.**dB
:CALCulate:PARameter[:CATegory]:NF:MDIFf<wsp>
<NRf>[DB]
INTERPOLATION SETTING
OFFSET(IN) **.**dB
:CALCulate:PARameter[:CATegory]:NF:IOFFset<wsp>
<NRf>[DB]
OFFSET(OUT) **.**dB
:CALCulate:PARameter[:CATegory]:NF:OOFFset<wsp>
<NRf>[DB]
ASE ALGO
AUTO-FIX
:CALCulate:PARameter[:CATegory]:NF:AALGo<wsp>
AFIX|0
MANUAL-FIX
:CALCulate:PARameter[:CATegory]:NF:AALGo<wsp>
MFIX|1
AUTO-CTR
:CALCulate:PARameter[:CATegory]:NF:AALGo<wsp>
ACENter|2
MANUAL-CTR
:CALCulate:PARameter[:CATegory]:NF:AALGo<wsp>
MCENter|3
FITTING AREA
:CALCulate:PARameter[:CATegory]:NF:FARea<wsp>
<NRf>[M]
MASK AREA
:CALCulate:PARameter[:CATegory]:NF:MARea<wsp>
<NRf>[M]
FITTING ALGO
LINEAR
:CALCulate:PARameter[:CATegory]:NF:FALGo<wsp>
LINear|0
GAUSS
:CALCulate:PARameter[:CATegory]:NF:FALGo<wsp>
GAUSs|1
LORENZ
:CALCulate:PARameter[:CATegory]:NF:FALGo<wsp>
LORenz|2
3RD POLY
:CALCulate:PARameter[:CATegory]:NF:FALGo<wsp>3RD|3
4TH POLY
:CALCulate:PARameter[:CATegory]:NF:FALGo<wsp>4TH|4
5TH POLY
:CALCulate:PARameter[:CATegory]:NF:FALGo<wsp>5TH 5
POINT DISPLAY
ON/OFF
:CALCulate:PARameter[:CATegory]:NF:PDISplay<wsp
>OFF|ON|0|1
NF CALCULATION SETTING
RES BW
:CALCulate:PARameter[:CATegory]:NF:RBWidth<wsp>
MEASured|CAL|0|1
SHOT NOISE
:CALCulate:PARameter[:CATegory]:NF:SNOise<wsp>O
FF|ON|0|1
FILTER-PK
SW ON/OFF
:CALCulate:PARameter[:CATegory]:FILPk<wsp>
PLEVel,SW,OFF|ON|0|1
PEAK WAVELENGTH
SW ON/OFF
:CALCulate:PARameter[:CATegory]:FILPk<wsp>
PWAVelength,SW,OFF|ON|0|1
CENTER WAVELENGTH
ALGO
:CALCulate:PARameter[:CATegory]:FILPk<wsp>
MWAVelength,ALGO,<data>
THRESH LEVEL
**.**dB
:CALCulate:PARameter[:CATegory]FILPk<wsp>
MWAVelength,TH,<NRf>[DB]
K
:CALCulate:PARameter[:CATegory]:FILPk<wsp>
MWAVelength,K,<NRf>
MODE FIT ON/OFF
:CALCulate:PARameter[:CATegory]:FILPk<wsp>
MWAVelength,MFIT,OFF|ON|0|1
7.3 ANALYSIS Setting Parameters
