YOKOGAWA AQ6370C

7-26
IM AQ6370C-17EN
ANALYSIS Parameters Control Command
FILTER BOTTOM
BOTTOM LEVEL
SW ON/OFF :
CALCulate:PARameter[:CATegory]:FILBtm
<wsp>BLEVel,SW,OFF|ON|0|1
BOTTOM WAVELENGTH
SW ON/OFF
:CALCulate:PARameter[:CATegory]:FILBtm
<wsp>BWAVelength,SW,OFF|ON|0|1
CENTER WAVELENGTH
SW ON/OFF
:CALCulate:PARameter[:CATegory]:FILBtm
<wsp>CWAVelength,SW,OFF|ON|0|1
ALGO
:CALCulate:PARameter[:CATegory]:FILBtm
<wsp>CWAVelength,ALGO,<data>
THRESH LEVEL**.**dB
:CALCulate:PARameter[:CATegory]:FILBtm
<wsp>CWAVelength,TH,<NRf>[DB]
CENTER WAVELENGTH
MODE DIFF *.**dB
:CALCulate:PARameter[:CATegory]:FILBtm
<wsp>CWAVelength,MDIFf,<NRf>[DB]
NOTCH WIDTH
SW ON/OFF
:CALCulate:PARameter[:CATegory]:FILBtm
<wsp>NWIDth,SW,OFF|ON|0|1
ALGO
:CALCulate:PARameter[:CATegory]:FILBtm
<wsp>NWIDth,ALGO,<data>
THRESH LEVEL **.**dB
:CALCulate:PARameter[:CATegory]:FILBtm
<wsp>NWIDth,TH,<NRf>[DB]
MODE DIFF *.**dB
:CALCulate:PARameter[:CATegory]: FILBtm
<wsp>NWIDth,MDIFf,<NRf>[DB]
CROSS TALK
SW ON/OFF
:CALCulate:PARameter[:CATegory]:FILBtm
<wsp>XTALk,SW,OFF|ON|0|1
ALGO
:CALCulate:PARameter[:CATegory]:FILBtm
<wsp>XTALk,ALGO,<data>
THRESH LEVEL **.**dB
:CALCulate:PARameter[:CATegory]:FILBtm
<wsp>XTALk,TH,<NRf>[DB]
MODE DIFF *.**dB
:CALCulate:PARameter[:CATegory]:FILBtm
<wsp>XTALk,MDIFf,<NRf>[DB]
CH SPACE ±*.**nm
:CALCulate:PARameter[:CATegory]:FILBtm
<wsp>XTALk,CSPace,<NRf>[M]
SEARCH AREA ±*.**nm
:CALCulate:PARameter[:CATegory]:FILBtm
<wsp>XTALk,SARea,<NRf>[M]
WDM FIL-PK (It is not available on the AQ6373/AQ6373B.)
CHANNEL DETECTION/ NOMINAL WAVELENGTH
ALGO
:CALCulate:PARameter[:CATegory]:WFPeak
<wsp>NWAVelength,ALGO,<data>
THRESH LEVEL **.**dB
:CALCulate:PARameter[:CATegory]:WFPeak
<wsp>NWAVelength,TH,<NRf>[DB]
MODE DIFF *.**dB
:CALCulate:PARameter[:CATegory]:WFPeak
<wsp>NWAVelength,MDIFf,<NRf>[DB]
TEST BAND *.***nm
:CALCulate:PARameter[:CATegory]:WFPeak
<wsp>NWAVelength,TBANd<NRf>[DB]
PEAK WAVELENGTH/LEVEL
SW ON/OFF
:CALCulate:PARameter[:CATegory]:WFPeak
<wsp>PWAVelength,SW,OFF|ON|0|1
7.3 ANALYSIS Setting Parameters
