ANALYSIS Parameters Control Command
WDM FIL-PK
XdB WIDTH/CENTER WAVELENGTH
SW ON/OFF
:CALCulate:PARameter[:CATegory]:WFPeak<wsp>
CWAVelength,SW,OFF|ON|0|1
THRESH LEVEL
**.**dB
:CALCulate:PARameter[:CATegory]:WFPeak<wsp>
CWAVelength,TH,<NRf>[DB]
XdB STOP BAND
SW ON/OFF
:CALCulate:PARameter[:CATegory]:WFPeak<wsp>
SBANd,SW,OFF|ON|0|1
THRESH
LEVEL**.**dB
:CALCulate:PARameter[:CATegory]:WFPeak<wsp>
SBANd,TH,<NRf>[DB]
XdB PASS BAND
SW ON/OFF
:CALCulate:PARameter[:CATegory]:WFPeak<wsp>
PBANd,SW,OFF|ON|0|1
THRESH LEVEL
:CALCulate:PARameter[:CATegory]:WFPeak<wsp>
PBANd,TH,<NRf>[DB]
TEST BAND
*.***nm
:CALCulate:PARameter[:CATegory]:WFPeak<wsp>
PBANd,TBANd,<NRf>[DB]
RIPPLE
SW ON/OFF
:CALCulate:PARameter[:CATegory]:WFPeak<wsp>
RIPPle,SW,OFF|ON|0|1
TEST BAND
*.***nm
:CALCulate:PARameter[:CATegory]:WFPeak<wsp>
RIPPle,TBANd,<NRf>[DB]
CROSS TALK
SW ON/OFF
:CALCulate:PARameter[:CATegory]:WFPeak<wsp>
XTALk,SW,OFF|ON|0|1
SPACING *.**nm
:CALCulate:PARameter[:CATegory]:WFPeak<wsp>
XTALk,SPACing,<NRf>[M]
TEST BAND *.***nm
:CALCulate:PARameter[:CATegory]:WFPeak<wsp>
XTALk,TBANd,<NRf>[DB]
WDM FIL-BTM (It is not available on the AQ6373/AQ6373B.)
CHANNEL DETECTION/ NOMINAL WAVELENGTH
ALGO
:CALCulate:PARameter[:CATegory]:WFBottom<wsp>
NWAVelength,ALGO,<data>
THRESH
LEVEL**.**dB
:CALCulate:PARameter[:CATegory]:WFPeak<wsp>
WFBottom,TH,<NRf>[DB]
MODE DIFF *.**dB
:CALCulate:PARameter[:CATegory]:WFBottom<wsp>
NWAVelength,MDIFf,<NRf>[DB]
TEST BAND *.***nm
:CALCulate:PARameter[:CATegory]:WFBottom<wsp>
NWAVelength,TBANd<NRf>[DB]
BOTTM WAVELENGTH/LEVEL
SW ON/OFF
:CALCulate:PARameter[:CATegory]:WFBottom<wsp>
BWAVelength,SW,OFF|ON|0|1
XdB NOTCH WIDTH/CENTER
SW ON/OFF
:CALCulate:PARameter[:CATegory]:WFBottom<wsp>
CWAVelength,SW,OFF|ON|0|1
XdB STOP BAND
ALGO
:CALCulate:PARameter[:CATegory]:WFBottom<wsp>
SBANd,ALGO,<data>
THRESH LEVEL
**.**dB
:CALCulate:PARameter[:CATegory]:WFBottom<wsp>
SBANd,TH,<NRf>[DB]
XdB ELIMINATION BAND
SW ON/OFF
:CALCulate:PARameter[:CATegory]:WFBottom<wsp>
EBANd,SW,OFF|ON|0|1
7.3 ANALYSIS Setting Parameters
