7-28
IM AQ6370C-17EN
ANALYSIS Parameters Control Command
WDM FIL-BTM
XdB ELIMINATION BAND
THRESH LEVEL
**.**dB
:CALCulate:PARameter[:CATegory]:WFBottom<wsp>
EBANd,TH,<NRf>[DB]
TEST BAND *.***nm
:CALCulate:PARameter[:CATegory]:WFBottom<wsp>
EBANd,TBANd,<NRf>[DB]
RIPPLE
SW ON/OFF
:CALCulate:PARameter[:CATegory]:WFBottom<wsp>
RIPPle,SW,OFF|ON|0|1
TEST BAND *.***nm
:CALCulate:PARameter[:CATegory]:WFBottom<wsp>
RIPPle,TBANd,<NRf>[DB]
CROSS TALK
SW ON/OFF
:CALCulate:PARameter[:CATegory]:WFBottom<wsp>
XTALk,SW,OFF|ON|0|1
SPACING *.**nm
:CALCulate:PARameter[:CATegory]:WFBottom<wsp>
XTALk,SPACing,<NRf>[M]
TEST BAND *.***nm
:CALCulate:PARameter[:CATegory]:WFBottom<wsp>
XTALk,TBANd,<NRf>[DB]
Parameter Corresponding to <ANALYSIS PARAMETER> of the Data Logging
Function
The parameter corresponding to <ANALYSIS PARAMETER> accessed through
ADVANCE -> <DATA LOGGING> -> <SETUP> varies depending on the logging item.
When the Logging Item Is WDM
The ANALYSIS2 parameter accessed through the ANALYSIS key in this section
corresponds to <ANALYSIS PARAMETER>.
When the Logging Item Is DFB-LD
The ANALYSIS1 parameter accessed through the ANALYSIS key in this section
corresponds to <ANALYSIS PARAMETER>.
7.3 ANALYSIS Setting Parameters
