YOKOGAWA BT200 User Manual

<Toc> <Ind> <2. INTRODUCTION TO BT200>
2-3
IM 01C00A11-01E
2.2 SPECIFICATION
Equipment Specifications
Applicable Equipment
DPharp Series
ADMAG Series
YEWFLO Series
YTA Series
CENTUM, Signal Conditioner
Communication Signal Connection:
Dedicated cable, 1.1 m long(3.6 ft)
Communication Line:
Line length: Up to 2 km (1.24 mile)(0.75 to 1.25
mm
2
instrumentation cable)
Load resistance: 250 to 600 Ω (including cable
resistance)
Load capacitance: 0.22µF or less
Load inductance: 3.3 mH or less
Power line spacing: 15 cm (6 inch) or more (avoid
parallel wiring.)
Display: LCD dot matrix, 21 characters  8 lines
Controls: Membrane switches (four function keys, 20
general operation keys, and one power switch)
Printer (BT200-P00): Thermal paper type
Power Supply: Five AA 1.5 V dry alkali batteries
(LR6/AM3(N))
Dimensions:
BT200-N00 · · · 22811051 mm
(9.04.32.0 inch)
BT200-P00 · · · 32111061 mm
(12.64.32.4 inch)
Approximate Weight:
BT200-N00 · · · 510 g (1.12 lb)
BT200-P00 · · · 700 g (1.54 lb)
Functional Specifications
Basic Functions:
•Setup, alteration, and display of parameters
BRAIN communication.
Additional Functions:
• Batch upload/download of data
• Setpoint Protection: Security code enter is required
to alter setpoints.
• Battery Alarm ··· An alarm message appearing on
the LCD signals low battery voltages.
