YOKOGAWA BT200 User Manual

5-8
<Toc> <Ind> <5. USING THE BT200 FUNCTIONS >
IM 01C00A11-01E
(6) PRINTING A LIST OF SELF-CHECK INFOR-
MATION
PARAM
C10:TAG NO.
TABC-101
C20:PRESS UNIT
mmH2O
C21:LRV
 0 mmH2O
DATA DIAG PRNT ESC
F0509.EPS
1.Press [F2] DIAG on the
parameter panel to call self-
check panel .
2.Press [F3] PRNT to start
printing.
1
䊊
2
䊊
DIAG
C60:SELF CHECK
ERROR
<ERROR >
<OUT OF RANGE >
<OVER SENS TEMP>
<OVER OUTPUT >
FEED  PRNT ESC
1
䊊
[F1] FEED
[F3] PRNT

[F4] ESC
➝Paper feed
➝Print out self-check
information.
➝Return to the
parameter panel .
1
䊊
5.3 OFFLINE FUNCTIONS
--WELCOME--
BRAIN TERMINAL
ID:BT200

check connection
push ENTER key
UTIL FEED  
F0510.EPS
UTILITY
1.ID
2.SECURITY CODE
3.LANGUAGE SELECT
4.LCD CONTRAST
5.PRINTER ADJUST
ESC
Call The Offline Menu (UTILITY PANEL)
