<APPENDIX 7. LINK MASTER FUNCTIONS>
A7-5
IM 01F06F00-01EN
Index
(SM)
Parameter Name
Sub-parameter Name
(Sub Index)
Default Factory
Setting
Access Remarks
370 PLME_BASIC_
CHARACTERISTICS
0 R
1 ChannelStatisticsSupported 0x00
2 MediumAndDataRatesSupported 0x4900000000000000
3 IecVersion 1 (0x1)
4 NumOfChannels 1 (0x1)
5 PowerMode 0 (0x0)
371 CHANNEL_STATES 0 R
1 channel-1 0 (0x0)
2 channel-2 128 (0x80)
3 channel-3 128 (0x80)
4 channel-4 128 (0x80)
5 channel-5 128 (0x80)
6 channel-6 128 (0x80)
7 channel-7 128 (0x80)
8 channel-8 128 (0x80)
372 PLME_BASIC_INFO 0 R
1 InterfaceMode 0 (0x0)
2 LoopBackMode 0 (0x0)
3 XmitEnabled 1 (0x1)
4 RcvEnabled 1 (0x1)
5 PreferredReceiveChannel 1 (0x1)
6 MediaTypeSelected 73 (0x49)
7 ReceiveSelect 1 (0x1)
373 LINK_SCHEDULE_ACTIVATION_VARIABLE RW
374 LINK_
SCHEDULE_LIST_
CHARACTERISTICS_
RECORD
0 R
1 NumOfSchedules 0
2 NumOfSubSchedulesPerSchedule 1
3 ActiveScheduleVersion 0
4 ActiveSheduleOdIndex 0
5 ActiveScheduleStartingTime 0
375 DLME_SCHEDULE_
DESCRIPTOR.1
0 R
1 Version 0
2 MacrocycleDuration 0
3 TimeResolution 0
376 DLME_SCHEDULE_
DESCRIPTOR.2
0 R
1 Version 0
2 MacrocycleDuration 0
3 TimeResolution 0
377 DOMAIN.1 Read/write impossible.
Get-OD possible.
378 DOMAIN.2 Read/write impossible.
Get-OD possible.
