<5. CONFIGURATION>
5-11
IM 01F06F00-01EN
Table 5.13 View Objects for Each AI Function
Block
Relative
Index
Parameter
Mnemonic
VIEW_
1
VIEW_
2
VIEW_
3
VIEW_
4
1 ST_REV 2 2 2 2
2 TAG_DESC
3 STRATEGY 2
4 ALERT_KEY 1
5 MODE_BLK 4 4
6 BLOCK_ERR 2 2
7 PV 5 5
8 OUT 5 5
9 SIMULATE
10 XD_SCALE 11
11 OUT_SCALE 11
12 GRANT_DENY 2
13 IO_OPTS 2
14 STATUS_OPTS 2
15 CHANNEL 2
16 L_TYPE 1
17 LOW_CUT 4
18 PV_FTIME 4
19 FIELD_VAL 5 5
20 UPDATE_EVT
21 BLOCK_ALM
22 ALARM_SUM 8 8
23 ACK_OPTION 2
24 ALARM_HYS 4
25 HI_HI_PRI 1
26 HI_HI_LIM 4
27 HI_PRI 1
28 HI_LIM 4
29 LO_PRI 1
30 LO_LIM 4
31 LO_LO_PRI 1
32 LO_LO_LIM 4
33 HI_HI_ALM
34 HI_ALM
35 LO_ALM
36 LO_LO_ALM
37 TOTAL 4
38 TOTAL_START
39 TOTAL_RATE_VAL
40 TOTAL_RESET
Total bytes 31 26 35 46
Note: AI2 and AI3 blocks do not have parameters after index
No. 37 (TOTAL) inclusive.
Table 5.14 View Objects for Each DI Function
Block
Relative
Index
Parameter
Mnemonic
VIEW_
1
VIEW_
2
VIEW_
3
VIEW_
4
1 ST_REV 2 2 2 2
2 TAG_DESC
3 STRATEGY 2
4 ALERT_KEY 1
5 MODE_BLK 4 4
6 BLOCK_ERR 2 2
7 PV_D 2 2
8 OUT_D 2 2
9 SIMULATE_D
10 XD_STATE 2
11 OUT_STATE 2
12 GRANT_DENY 2
13 IO_OPTS 2
14 STATUS_OPTS 2
15 CHANNEL 2
16 PV_FTIME 4
17 FIELD_VAL_D 2 2
18 UPDATE_EVT
19 BLOCK_ALM
20 ALARM_SUM 8 8
21 ACK_OPTION 2
22 DISC_PRI 1
23 DISC_LIM 1
24 DISC_ALM
Total bytes 22 8 22 19
