YOKOGAWA digitalYEWFLO Series User Manual

<5. CONFIGURATION>
5-13
IM 01F06F00-01EN
Relative
Index
Parameter
Mnemonic
VIEW_
1
VIEW_
2
VIEW_
3
VIEW_
4
1 ST_REV 2
2 2 2
2
TAG_DESC
3
STRATEGY 2
4
ALERT_KEY 1
5
MODE_BLK 4 4
6
BLOCK_ERR 2 2
7
PV 5 5
8
OUT 5 5
9
PRE_OUT 5 5
10
PV_SCALE 11
11
OUT_RANGE 11
12
GRANT_DENY 2
13
INPUT_OPTS 2
14
IN 5
15
IN_LO 5
16
IN_1 5
17
IN_2 5
18
IN_3 5
19
RANGE_HI 4
20
RANGE_LO 4
21
BIAS_IN_1 4
22
GAIN_IN_1 4
23
BIAS_IN_2 4
24
BIAS_IN_2 4
25
BIAS_IN_3 4
26
BIAS_IN_3 4
27
COMP_HI_LIM 4
28
COMP_LO_LIM 4
29
ARITH_TYPE 1
Relative
Index
Parameter
Mnemonic
VIEW_
1
VIEW_
2
VIEW_
3
VIEW_
4
30
BAL_TIME 4
31
BIAS 4
32
GAIN 4
33
OUT_HI_LIM 4
34
OUT_LO_LIM 4
35
UPDATE_EVT
36
BLOCK_ALM
37
AR_VOLUME_
FLOW_UNIT
2
38
AR_TEMP_UNIT 2
39
AR_BASE_TEMP 4
40
AR_PRESSURE_
UNIT
2
41
AR_BASE_
PRESSURE
4
42
AR_DEVIATION 4
43
AR_DENSITY_
UNIT
2
44
AR_BASE_
DENSITY
4
45
AR_FIRST_TEMP_
COEF
4
46
AR_SECOND_
TEMP_COEF
4
47
AR_FLOW_
CONFIG
48
AR_DENSITY_
FACTOR
5
49
AR_DENSITY_
FACTOR_UNIT
2
50
AR_CONFIG_
SOFT_REV
51
AR_CONFIG_DATE
52
AR_CONFIG_WHO
53
AR_CONFIG_
STATUS
54
AR_CONFIG_
VSTRING32
55
AR_CONFIG_
VSTRING16
56
AR_CONFIG_
OSTRING32
57
AR_CONFIG_
OSTRING2
Total bytes 23 26 53 102
Table 5.16 View Objects for Enhanced Arithmetic (AR) Block
