YOKOGAWA digitalYEWFLO Series User Manual

<10. EXPLOSION PROTECTED TYPE INSTRUMENT>
10-6
IM 01F06F00-01EN
Type of Protection : Intrinsically Safe for Class I,
II, III, DIV.1, Groups A, B, C, D, E, F and G,
T4, and Class I, Zone 0, AEx ia IIB/IIC T4,
Entity, FISCO
Nonincendive for Class I, II, Div.2, Groups
A, B, C, D, F and G, Class III, DIV.1, Class I,
Zone 2, Group IIC, FNICO
Ambient Temperature :
–40 to +60°C (Integral Type and Vortex Flow
Converter)
–40 to +80°C (Remote Type Detector)
Indoors and Outdoors : Type 4X
Electrical Parameters : Intrinsically Safe
[Entity] Vmax=24 V, Imax=250 mA,
Pi=1.2 W, Ci=3.52 nF, Li=0 mH
[FISCO (IIC)] Vmax=17.5 V, Imax=380 mA,
Pi=5.32 W, Ci=3.52 nF, Li=0 mH
[FISCO (IIB)] Vmax=17.5 V, Imax=460 mA,
Pi=5.32 W, Ci=3.52 nF, Li=0 mH
Nonincendive
Vmax=32 V, Ci=3.52 nF, Li=0 mH
Electrical Connection : ANSI 1/2NPT female
(2) Wiring
•Explosionproof
WARNING
• All wiring shall comply with National
Electrical Code ANSI/NFPA 70 and Local
Electrical Code.
• “SEAL ALL CONDUITS 18 INCHES”
“ WHEN INSTALLED DIV.2, SEALS NOT
REQUIRED”.
•IntrinsicallySafe
NOTE
If you are using a hand-held terminal in the
hazardous area, read the Control Drawing or
Instruction Manual of handheld terminal.
(3) Operation
•Explosionproof
WARNING
• In case of Explosion proof, note a warning
label worded as follows.
Warning: OPEN CIRCUIT BEFORE
REMOVING COVER.
INSTALL IN ACCORDANCE WITH
THE INSTRUCTION MANUAL (IM)
01F06A00-01EN.
• Take care not to generate mechanical
spark when access to the instrument and
peripheral devices in hazardous locations.
(4) Maintenance and Repair
WARNING
The instrument modication or part replacements
by other than authorized representative of
Yokogawa Electric Corporation is prohibited and
will void the approval of FM Approvals.
