Terminal Arrangement
Term. No. Symbol Term. No. Symbol
21 CH6 + 11 CH1
+
22 − 12 −
23 CH7 + 13 CH2 +
24 − 14 −
25 CH8 + 15 CH3 +
26 − 16 −
27 CH9 + 17 CH4 +
28 − 18 −
29 CH10 + 19 CH5 +
30 − 20 −
Negative terminal (common) potential shared
+
−
5V DC
approx.5kΩ
Input type:
Photocoupler isolation
Negative terminal (common)
potential shared
Allowable input voltage:±10V
Note: Do not apply voltage outside the allowable input
voltage range across input terminals. Doing so can cause
a malfunction.
Wiring to a GX90YA Analog Output Module
Terminal Diagram
CH1+
CH4+
(11)
CH1–
(12)
(17)
CH4–
(18)
CH1+
CH4+
(18)
M3 screw terminal Clamp terminal
Wiring direction
Wiring direction
Terminal Arrangement
Term. No. Symbol
11 CH1 +
12 -
13 CH2 +
14 -
15 CH3 +
16 -
17 CH4 +
18 -
19 Not Used
20 Not Used
Installation and Wiring
Wiring to a GX90WD Digital Input /Output Module
Terminal Diagram
M3 screw terminal
Wiring direction
DI
301/201/101
302/202/102
303/203/103
310/210/110
DO
305/205/105
Terminal Arrangement
CH
No.
Term.
No.
Symbol Term.
No.
Symbol Term.
No.
Symbol
DI1 to
DI8
301 DI3 201 DI2 101 DI1
302 DI6 202 DI5 102 DI4
303 DICOM 203 DI8 103 DI7
-
304 - 204 - 104 -
DO1 305 DO1NO 205 DO1COM 105 DO1NC
DO2 306 DO2NO 206 DO2COM 106 DO2NC
DO3 307 DO3NO 207 DO3COM 107 DO3NC
DO4 308 DO4NO 208 DO4COM 108 DO4NC
DO5 309 DO5NO 209 DO5COM 109 DO5NC
DO6 310 DO6NO 210 DO6COM 110 DO6NC
DI1 to
DI18
DICOM
Input type:
Photocoupler isolation
Shared common (DICOM)
Allowable input voltage range:
0 to 10V
Note: Do not apply voltage outside the allowable input
voltage range across input terminals. Doing so can cause
a malfunction.
Wiring to a GX90XP Pulse Input Module
Terminal Diagram
M3 screw terminal
Wiring direction
Clamp terminal
Wiring direction
CH1 +
CH5 +
CH5 –
CH6 +
CH10 +
(11)
(19)
CH10 −
CH1 –
(20)
CH10 −
CH6 +
CH10 +
CH1 +
CH5 +
CH5 −
