Pressure Measuring Elements
CMPL 06P01B01-02E
8th Edition: Nov. 2015 (YK)
Spiral Element (P42) and Mounting Parts
Spiral Element Assembly
for ranges 0.10 to 0.14 MPa
for ranges 0.15 to 0.21 MPa
for ranges 0.22 to 0.27 MPa
for ranges 0.28 to 0.34 MPa
for ranges 0.35 to 0.41 MPa
for ranges 0.42 to 0.55 MPa
for ranges 0.56 to 0.69 MPa
for ranges 0.70 to 0.82 MPa
for ranges 0.83 to 1.03 MPa
for ranges 1.04 to 1.37 MPa
Adapter Plate
Pan H. Screw, M4 x 8
Column
Screw
Tube
Compression Screw
Sleeve
Nut
Link Assembly
1
2
3
4
5
6
7
8
9
10
Below
P0106MZ
P0106NA
P0106NB
P0106NC
P0106NE
P0106NF
P0106NK
P0106NL
P0106NM
P0106NN
0041518
Y9408JS
F9123JJ
F9147CW
F9123JP
B0102XK
B0102XL
P0106KF
X0101BE
1
1
2
2
1
1
1
2
1
1
Item Part No. Description
Qty
