11-6. User setting table
FUNCTION SETTING DEFAULTS USER SETTINGS
Parameter specific functions
01 *SC.RES 0 SC
02 *4.ELEC 0 2-Elec.
03 *0.10xC 0.10xC Factor
1.000 /cm
04 *AIR
05 *POL.CK 1 On
Temperature measuring functions
10 *T.SENS 0 Pt1000
11 *T.UNIT 0 °C
12 *T.ADJ None
Temperature compensation functions
20 *T.R.°C 25 °C
21 *T.C.1 2.1 %/°C
*T.C.2 2.1 %/°C
22 *MATRX None, see 5-2-5
23 *T1°C T. range See sep. table, 11-2
24 *L1xT1 Cond. C1 See sep. table, 11-2
25 *L2xT1 Cond. C2 See sep. table, 11-2
26 *L3xT1 Cond. C3 See sep. table, 11-2
27 *L4xT1 Cond. C4 See sep. table, 11-2
28 *L5xT1 Cond. C5 See sep. table, 11-2
mA outputs
31 *OUTP.F 0 Linear S.C.
32 *BURN 0 No Burn
35 *TABLE 21 pt table see code 31, 11-1
mA
To Next Page
